Q45UBB63BC Proximity Sensor PNP Output
Discrete Q45U Series: Proximity Mode
Range: 250 mm - 3 m; Input: 12-24V dc
Output: Bipolar: 1 NPN; 1 PNP
2 m (6.5 ft) Cable
Part No.： 46360
Sensing Mode (General) Proximity
Sensing Mode (Detailed) Time of Flight
Housing Style Rectangular
Primary Housing Material PBT
Input/Output Discrete
Indicator LED(s)
Analog Resolution/Discrete Repeatability +/- 0.1% of measured distance (+/- 0.25 min)
Max Sensing Distance (mm) 3000
Minimum Sensing Distance (mm) 250
Sensing Beam Ultrasonic
Power Supply 12-24 V dc
Adjustments Teach Button; DIP Switches
Temperature Effect (mm/°C) 0.05% of sensing distance/°C
Connection Cable
QD Type/Cable Length 2 m
Number of Pins 5
Vibration MIL-STD-202F req. Method 201A (vibration:10 to 60Hz max., double amplitude 0.06", max acc. 10G).
Mechanical Shock IEC 60947-5-2 requirements: 30G 11 ms duration, half sine wave
Output Saturation Voltage NPN Outputs
Output Saturation Voltage PNP Outputs
Max Discrete (Switched) Output (mA) 150
Discrete (Switched) Outputs Bipolar (NPN & PNP)
Output Protection Protected against false pulse on power-up and continuous overload or short-circuit of outputs
IP Rating IP67
NEMA Rating NEMA 6P
Max Operating Temperature (°C) 70
Min Operating Temperature (°C) -25
Max Op. Relative Humidity Non-Condensing (%) 100
Warm-up Time (minutes) 15
Minimum Response Time (ms) 40
Minimum Window Size (mm) 25
Discrete Output Hysteresis (mm) 10
Ultrasonic Frequency (kHz) 128
Max Off-state Leakage Current (µA) 25
Power/Current Consumption (exclusive of load) 100 mA
Supply Protection Circuitry Protected against reverse polarity and transient overvoltages
Feature: Remote Teach Yes
Feature: Clear Object Detection Yes
Feature: Timing (Hold/Delay) No
Feature: Chemical Resistant No
Feature: Pump-in/ Pump-out Yes
Application: Ultrasonic Yes
SMB30MM
Bracket: 30mm; Material: 12 Gauge Stainless Steel; Curved mounting slot for versatility/orientation ; Clearance for M6 (1/4 in.) hardware
SMB30S
Bracket: Plastic; Material: Black Polyester; 30 mm Swivel; Hardware included
SMB30C
Bracket: Stainless Steel Mounting; Material: Black VALOX; 30mm split clamp ; Hardware included
