EZ-ARRAY Receiver BANNER EA5R300PIXMODQ
- SHANGHAI
- T/T
- 30 days
You May Like
Product Details
| Brand Name | BANNER | Place of Origin | China | |
| Model Number | EA5R300PIXMODQ | Usage | Magnetic Sensor | |
| Theory | Optical Sensor | Output | Digital Sensor |
Product Description
EZ-ARRAY Receiver BANNER EA5R300PIXMODQ
EZ-ARRAY Receiver: 300 mm (11.8 in.)
Range: (matching emitter sold separately) 400 mm - 4 m; Input: 12-30 V dc
Outputs: 2 Solid-State PNP 2 Analog 4-20 mA EIA-4
Euro 8-pin Quick-Disconnect
77528
Sensing Mode (Detailed) Receiver
Device Type Two-Piece
Primary Housing Material Aluminum
Beam Spacing 5 mm
DeviceNet No
IO Link No
Modbus RTU Yes
RS-232 No
RS-485 Yes
Number of Beams 60
Min Temp (°C) -40
Housing Length (mm) 379
Array Length (mm) 300
Max Temp (°C) 70
Minimum Object Sensitivity (mm) 5-10
Discrete Output PNP
Emitter/Receiver Range (m) 0.4 - 4
Max Relative Humidity 95%
Power Supply 12-30V dc
Analog Output Current (4-20 mA)
