Solar panel hail impact machine/PV Module impigement testing machine/lash testing equipment with IEC61215-2:2016 standard
Testing standard
It's conform IEC61215-2:2016 testing standard
Purpose
to verify that the module is capable of withstanding the impact of hailstones
The Main Technical Specifications
| Testing standard | IEC61215-2:2016& IEC61730-2:2016 |
launch device |
a.Power source is air compressor b.Air pressure:6-8bar c.Ice ball single filled by manual d.The barrel length approx 940mm e.The barrel can change |
| Moving locating device |
a.X shaft move distance approx 2100mm b.Y shaft move distance approx 1000mm c.Locating accurate:≤1mm d.Impact area:2000×1000mm e.Guide ways is high quality import guide rail f.Driving ways adopt import servo motor + synchronous wheel g.Locating control ways is PC control and automatic locating |
| Testing velocity | 0-50m/s |
| Ice ball diameter | 25mm, 35mm, 45mm ,55mm,65mm,75mm |
| Make ice ball mould | every ice ball diameter attched 2 sets mould |
| Control ways | Computer control |
| Electricity | 220V 50HZ |
| Impact point | According to the standard with 11 impact point |
