Backboard resist scuffing testing equipment/Solar panel cut susceptibility testing machine/ solar panel testing machine
Testing standard
It's conform IEC61730-2:2016 testing standard
Purpose
It's to determine whether any front and rear surfaces of the pv module made of polymeric materials are capable of withstanding routine handling during installation and maintenance without exposing personnel to the danger of electric shock
The Main Technical Specifications
| Testing standard | IEC61730-2:2016 testing standard |
Test stand frame |
a. The raw materials: Aluminum profile ( Firm and Antirust) b.The testing sample standard dimension:2m×1m (customized) c. Included the Tracking pulley wheel |
|
Testing Fixture |
a. The raw material:Use adopt carbon steel blade b. The steel blade thickness:0.64mm±0.05mm ( It’s suffficiently rigid as not to be bend sideways during the test) c.The top angle of steel blade :90±2° and with rounded with radius 0.115mm±0.025mm d. The blade supply the force : 8.9N±0.5N
|
| Advantage |
Use motor constant speed tracking , speed can set, tracking directing can adjustable |
| The test fixture speed |
150±30mm/s |
| Control ways and display ways |
Touch screen |
| Electricity | 220V 50HZ |
