IEC 61215 Standard Solar Panel Dynamic Static Mechanical Load Testing Machine/PV Module Testing Machine
US$ 36,764.71 - 47,058.82
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
HOTOTECH
Place of Origin:
Guangdong, China
Model Number:
HTPV-08FG
Payment & Shipping
Payment Methods:
Port of Shipment:
ShenZhen YanTian
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
PV Module Hail Tester /Solar Panel Testing Machine / Solar Panel Ice Ball Impact Testing EquipmentUS$ 40,630.35 - 40,630.35MOQ: 1 Set -
New Energy Industry IEC61215-2:2016 Standard Solar Panel Impact Tester Testing Machine for pv ModuleUS$ 600 - 1,200MOQ: 1 Set
-
IEC 61215 IEC 61646 Standard Solar Panel PV Module Hail Impact Testing Machine for Solar Energy IndustryUS$ 22,058.82 - 26,470.59MOQ: 1 Set
-
Solar Panel Hail Impact Machine/impigement Testing Machcine/lash Testing Equipment With IEC61215-2:2016 StandardUS$ 1,200 - 1,400MOQ: 1 Set
-
Satisfy IEC61215-2:2016 Standard Solar Panel Hail Impact Tester /Hit Testing Machine /Crash Testing ApparatusUS$ 9,000 - 10,000MOQ: 1 Set
Brand Name
HOTOTECH
Place of Origin
Guangdong, China
Model Number
HTPV-08FG
Power
Electronic
Company logo
Product Description
IEC 61215 standard Solar panel Dynamic Static Mechanical Load Testing Machine/PV Module testing machine
Standard:
It's conform IEC61215-2:2016 testing standard
Purpose
This test is to determine the ability of the module to withstand wind, snow , staitc or ice loads
The Main technical specifications
| Product Name | IEC61215 standard solar panel dynamic static mechanical load testing machine/PV Module testing machine |
| Testing standard | IEC61215-2:2016 |
| Testing samples | Solar panel |
| Testing sample quantity | 1 pcs |
| The sample size | 2m×1m (customized) |
| Test positive load | 5400 pa |
| The reverse load | 2400pa |
| Dynamic load test frequency | 7s±3s |
| Dynamic load | 1000Pa, 1000times |
| Pressure control accurate | 5% |
| Pneumatic and force value feedback ways | low friction force cylinder, tension pressure sensor (accurate 0.1N) |
| Aluminum profile structure feature | platform fixture , according to determined install ways to do the adjsutable |
| Current continuity system | DC Power, DC 150V/2A , real-time monitor module inner current continuity |
| Cylinder | 4groups , in total 8 pieces, single the maximum output >200kg, telescopic stroke125mm |
| Sucker | 8 groups, in total 32 pieces , sucker diameter 120mm |
| Control ways | Computer control |
| Data show | Real-time curve show , data can save and print |
| Electricity | 220V 50HZ |
Products images show
