New Energy Industry IEC61215-2:2016 Standard Solar Panel Impact Tester Testing Machine for pv Module

FOB Price

US$ 600 - 1,200 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name	HOTOTECH		Place of Origin	Guangdong, China
Model Number	HTPV-09CD

New energy industry IEC61215-2:2016 Standard Solar panel Impact tester testing machine for pv module

Standard

According to IEC61215,UL1703

purpose

use to verification module resistance impact ability , artifical hockey use to simulate hail , and to the

constant speed impact component , simulate hail climate against component effect

specifications

1.Effective impact area:1200 * 2100mm

2.Standard hail diameter:25mm±5%

3.Standard hail mass:7.53g±5%

4.Hail setting speed:23.0m/s±5%

5.Speed measurement accurate :±2%

6.Hail mass measurement accurate:±2%

7.Pneumatic shoot system

8.Main function:

8.1,Chinese operate interface,setting impact position ,impact speed , hail reference ,time etc

reference.

8.2,two dimension stepping driving system , the interface can setting the displacement

8.3,can programme control automatic being multipoint impact test

8.4,the hail shoot speed through compression air’s pressure adjust

8.5,light spot fixed point collimation function ,convenience to ensure impact point position
