Digital Voltmeter Ammeter AC DC Voltage Resistance Tester Automatic Multimeter
- 50000 Set / Sets per Month
- shenzhen
- T/T Credit Card
- digital gas indicators Portable combustible gas detector
- Portable H2S gas detector, multi-gas detector CO and VOC
- Gas Detector For Combustible Gas/combustible gas leak detector
- Air quality Detector Testing PM2.5 PM10 CO2 TVOC Temperature Humidity
- Multi-Function Indoor environment Air Quality Tester
- 2018 New GFCI RCD Wall Socket Tester Voltage tester Socket Wire tester
Product Details
Brand Name: | HOTOTECH | Place of Origin: | Guangdong, China | Model Number: | MY8231S |
Operating Temperature: | Normal temperature | Dimensions: | 130mm*62mm*27mm | Measuring Inductance Range: | no |
Measuring Capacitance Range: | 20nF/200nF/2uF/20uF/200uF/2000uF | Measuring Resistance Range: | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ | Measuring Voltage Range: | 2V/20V/200V/600V |
Measuring Current Range: | 20mA/200mA |
Product Description
MY8231S
MINI Multimeter
product feature
-resistance measure up to 20mΩ with continuity detection
-voltege measurement
-manual power off
-low battery indication
-backlight
product image
Specifications
Model | MY8231S | ||
Range | Resolution | Accuracy | |
DC voltage | 2V/20V/200V | 0.001V/0.01V/0.1V | ±(0.5%+3) |
600V | 1V | ±(0.8%+5) | |
AC voltage | 2V/20V/200V | 0.001V/0.01V/0.1V | ±(0.8%+3) |
600V | 1V | ±(1.0%+5) | |
20mA/200mA | 0.01mA/0.1mA | ±(1.8%+5) | |
AC current | 20mA/200mA | 0.01mA/0.1mA | ±(2.0%+5) |
Resistance | 200Ω/2KΩ/20KΩ/200KΩ/2MΩ | 0.1Ω/0.0001KΩ/0.1KΩ/0.1Ω/0.001MΩ | ±(2.0%+5) |
20MΩ | 0.01MΩ | ±(2.0%+5) | |
Capacitance | 20nF | 0.01nF | ±(10%+40) |
200nF/2uF/20uF/200uF | 0.1nF/1nF/10nF/100nF | ±(2.5%+20) | |
2000uF | 1uF | ±(5%+10) | |
Diode | √ | ||
On / off buzzer | √ | ||
Zero / Firewire Identification | √ | ||
Backlight | √ | ||
Floodlight | √ | ||
NCV | √ | ||
Power supply | 2×1.5V AAA | ||
Weight | 150g | ||
Size | 130mm×62mm×27mm | ||
Safety level | EN61010-1,-2-030,EN61010-2-033, EN613261,CAT.III 600V |
Matters needing attention
Do not use the instrument around explosive gas or steam or in humid environment
Do not use a damaged stylus. check whether the insulating layer of the stylus is damaged, whether there is metal leakage or signs of wear. check the on-off property of the stylus
When measuring, please connect the neutral line or ground line before connecting the live line. Please cut off the live wire before disconnecting, and disconnect the neutral wire and the ground wire.
When measuring, please hold your finger behind the stylus protector.
Before opening the back cover of the instrument, disconnect the probe from the object to be measured.
Do not use the meter in an environment that exceeds the CAT rating of the lowest rated single component in the meter, probe or accessory.
