Help CenterVibratory Hopper Feeder/Bin Discharger
Related Products
Features of Bin Activator
1. solution for flow problems : eliminate Bridging & Ratholing
2. fully sealed , without dust flying , protected environment;
3. suitable for powders and granule particles ,attached to any bin or silo;
4. simple structure , easy operation and maintenance;
5. low noise , low power consumption;
6. can be customized as per requirement.
Bin Flow Problems
Normally the storage bins have large cross sections with cone shaped small outlet at the bottom. then flow problems are easily cuased by materials wedging and compacting into the bottom of the bin
Bin Activator-------Solution for Flow Problem
The GZD series bin activator is a silo arch-breaking device. installed under the silo bottom , with good performance in eliminating bridge , reduce silo segregation promote mass flow , for continuous flow of dry bulk materials .can also used for stop feeding flow or control feeding flow.
Bin Activator Application
This Bin activator is suitable for all kinds of powder and granular materials .adapted to circular , square , steel or concrete silos.
Customize the Outlet of Your Bin Discharger
Outlet diameter can be customized as per required ;
height of outlet can be customized as per required;
a valve can be added to the outlet , to control flow;
a flange can be added to the outlet;
Parameters of Bin Activator
Model |
Vibration feeder diameter A(mm) |
Bunker diameter (m) |
Motor Power (kw) |
Flange outer diameter C(mm) |
Weight(kg) |
Excitation strength scope (kg) |
Discharge hole D(mm) |
GZD04 |
400 |
0.4-0.8 |
0.15 |
490 |
50 |
0-150 |
120 |
GZD06 |
600 |
0.6-1.2 |
0.2 |
710 |
100 |
0-250 |
150 |
GZD08 |
800 |
0.8-1.6 |
0.5 |
930 |
180 |
0-500 |
200 |
GZD10 |
1000 |
1.0-2.0 |
0.75 |
1130 |
300 |
0-1000 |
250 |
GZD12 |
1200 |
1.2-2.4 |
1.10 |
1330 |
450 |
0-1500 |
250 |
GZD15 |
1500 |
1.5-3.0 |
1.50 |
1660 |
650 |
0-2000 |
300 |
GZD20 |
2000 |
2.0-4.0 |
1.50 |
2200 |
1200 |
0-3000 |
400 |
Company Profile:
Xinxiang Gaozhuo vibrating equipment Co.,ltd with reliable product , reasonable charge , superior customer service , our company gains great reputation home and vide solutions for various materials screening , separating.
The production mainly includes: vibrating sieve machines , vibrating feeding machines , conveyor equipments , vibrating motors etc.
Welcome to visit and communicate.
