Home > Products > Submersible pump > LJC Vertical Turbine Pump
LJC Vertical Turbine Pump
- Shanghai
- T/T
- 20 days
You May Like
Product Details
| Brand Name | kenshine-pump | Place of Origin | China | |
| Model Number | 500LJC1250-30*2 | Application | Other, lift water, irrigation, booster | |
| Fuel | Other, electric motor | Power | Electric | |
| Usage | Water | Theory | Centrifugal Pump | |
| Standard or Nonstandard | Standard | Structure | Multistage Pump | |
| Pressure | Low Pressure |
Product Description
LJC Vertical turbine pump is used to transport the clean water as the submersible deep well pump. LJC submersible deep well pumps are new generation of energy saving equipment for lifting water. They have the advanced structure and hydraulic model, excellent performance curve without hump and wide high efficiency range. The efficiency is 4 to 8% higher than JC, JD deep well pumps.
The pumps adopt the core produced with the resin sand and impeller and diffuser adopt the new technique of top coated with epoxy. The pumps adopt whirl sand device and maze structure which make sand not able to enter the bearings. Shaft uses flame method to ensure it is in line.
LJC Vertical turbine pump are applied to lift clean water at normal temperature for water power station, power plant, steel factories, firefighting, urban water supply by water plant and agriculture irrigation etc.
Capacity: 6-5000m3/h
Head:30-350m
Motor power:5.5-1600KW
Well diameter: 100-950mm
Max. Discharge diameter:650mm
| Model | Flow | Head | stages | Motor power | string | Speed | Efficiency | impeller Diameter | ||
| m3/h | m | impeller | kW | mm | r/min | % | mm | |||
| 100LJC10-4 | 6.5 10 12 | 35 | 32 | 25.5 | 8 | 5.5 | 8 | 2940 | 62 | 92 |
| 44 | 40 | 32 | 10 | 5.5 | ||||||
| 53 | 48 | 38 | 12 | 5.5 | ||||||
| 61.5 | 56 | 44.5 | 14 | 5.5 | ||||||
| 70 | 64 | 51 | 16 | 5.5 | ||||||
| 79 | 72 | 57.5 | 18 | 5.5 | ||||||
| 88 | 80 | 64 | 20 | 5.5 | ||||||
| 96.5 | 88 | 70 | 22 | 5.5 | ||||||
| 105.5 | 96 | 76.5 | 24 | 5.5 | ||||||
| 115 | 104 | 83 | 26 | 5.5 | ||||||
| 150LJC10-9 | 8 10 16 | 74.5 | 72 | 54 | 8 | 5.5 | 12 | 2940 | 62 | 138 |
| 84 | 80 | 61 | 9 | 5.5 | ||||||
| 93 | 89 | 67.5 | 10 | 5.5 | ||||||
| 102.5 | 98 | 61.5 | 11 | 7.5 | ||||||
| 112 | 108 | 81 | 12 | 7.5 | ||||||
| 121 | 117 | 87.5 | 13 | 7.5 | ||||||
| 130 | 126 | 94.5 | 14 | 7.5 | ||||||
| 139.5 | 135 | 101 | 15 | 11 | ||||||
| 149 | 144 | 108 | 16 | 11 | ||||||
| 158 | 153 | 114.5 | 17 | 11 | ||||||
| 167 | 162 | 121.5 | 18 | 11 | ||||||
| 176.5 | 171 | 128 | 19 | 11 | ||||||
| 150LJC20-11 | 15 20 24 | 48 | 44 | 39.4 | 4 | 5.5 | 12 | 2940 | 67 | 150 |
| 60 | 55 | 49.3 | 5 | 5.5 | ||||||
| 84 | 77 | 69 | 7 | 7.5 | ||||||
| 108 | 99 | 88.6 | 9 | 11 | ||||||
| 132 | 121 | 108.2 | 11 | 15 | ||||||
| 156 | 143 | 128 | 13 | 15 | ||||||
| 180 | 165 | 147.5 | 15 | 18.5 | ||||||
| 204 | 187 | 167 | 17 | 18.5 | ||||||
| 150LJC30-12.5 | 12 30 36 | 69 | 62.5 | 51 | 5 | 11 | 8 | 2940 | 70 | 150 |
| 82.5 | 75 | 61 | 6 | 11 | ||||||
| 96.2 | 87.5 | 71.8 | 7 | 15 | ||||||
| 110.4 | 100 | 82 | 8 | 15 | ||||||
| 124 | 112.5 | 92.2 | 9 | 15 | ||||||
| 138 | 125 | 102.5 | 10 | 18.5 | ||||||
| 151.6 | 137.5 | 112.8 | 11 | 18.5 | ||||||
| 165 | 150 | 123 | 12 | 22 | ||||||
| 179.4 | 162.5 | 133.3 | 13 | 22 | ||||||
| 150LJC40-13.5 | 30 40 46 | 62 | 54 | 50 | 4 | 11 | 8 | 2940 | 72 | 150 |
| 77.5 | 67.5 | 62.5 | 5 | 15 | ||||||
| 93 | 81 | 75 | 6 | 15 | ||||||
| 108.5 | 94.5 | 87.5 | 7 | 18.5 | ||||||
| 124 | 108 | 100 | 8 | 18.5 | ||||||
| 139 | 121.5 | 112.5 | 9 | 22 | ||||||
| 155 | 135 | 125 | 10 | 30 | ||||||
| 170.5 | 148.5 | 137.5 | 11 | 30 | ||||||
| 186 | 162 | 150 | 12 | 30 | ||||||
| 150LJC50-13 | 30 50 55 | 66 | 52 | 46 | 4 | 11 | 8 | 2940 | 74 | 150 |
| 82.5 | 65 | 57.5 | 5 | 15 | ||||||
| 99 | 78 | 69 | 6 | 18.5 | ||||||
| 115.5 | 91 | 80.5 | 7 | 22 | ||||||
| 132 | 104 | 92 | 8 | 22 | ||||||
| 148.5 | 117 | 103.5 | 9 | 30 | ||||||
| 200LJC60-20 | 40 60 76 | 44 | 40 | 30 | 2 | 11 | 9 | 2940 | 75 | 181 |
| 66 | 60 | 45 | 3 | 18.5 | ||||||
| 88 | 80 | 60 | 4 | 22 | ||||||
| 110 | 100 | 75 | 5 | 30 | ||||||
| 132 | 120 | 90 | 6 | 37 | ||||||
| 154 | 140 | 105 | 7 | 37 | ||||||
| 200LJC80-22.5 | 60 80 100 | 49 | 45 | 38 | 2 | 15 | 9 | 2940 | 75 | 181 |
| 73.5 | 67.5 | 57 | 3 | 22 | ||||||
| 98 | 90 | 76 | 4 | 30 | ||||||
| 122.5 | 112.5 | 95 | 5 | 37 | ||||||
| 200LJC90-20 | 67 90 119 | 45 | 40 | 28 | 2 | 15 | 10 | 2940 | 75 | 190 |
| 68 | 60 | 43 | 3 | 22 | ||||||
| 91 | 80 | 57 | 4 | 30 | ||||||
| 114 | 100 | 72 | 5 | 37 | ||||||
| 200LJC125-18 | 89 125 146 | 21.5 | 18 | 15 | 1 | 11 | 10 | 2940 | 76 | 190 |
| 43 | 36 | 30 | 2 | 18.5 | ||||||
| 64.5 | 54 | 45 | 3 | 30 | ||||||
| 86 | 72 | 60 | 4 | 37 | ||||||
| 250LJC130-8.5 | 89 130 150 | 49 | 42.5 | 35 | 5 | 22 | 10 | 1460 | 78 | 242 |
| 59 | 51 | 42 | 6 | 30 | ||||||
| 69 | 59.5 | 49 | 7 | 37 | ||||||
| 79 | 68 | 56 | 8 | 37 | ||||||
| 89 | 76.5 | 63 | 9 | 45 | ||||||
| 99 | 85 | 70 | 10 | 45 | ||||||
| 109 | 93.5 | 77 | 11 | 55 | ||||||
| 119 | 102 | 84 | 12 | 55 | ||||||
| 300LJC160-11.5 | 125 160 200 | 39 | 34.5 | 28.5 | 3 | 22 | 14 | 1460 | 80 | 295 |
| 52 | 46 | 38 | 4 | 30 | ||||||
| 65 | 57.5 | 47.5 | 5 | 37 | ||||||
| 78 | 69 | 57 | 6 | 45 | ||||||
| 91 | 80.5 | 66.5 | 7 | 55 | ||||||
| 104 | 92 | 76 | 8 | 75 | ||||||
| 117 | 103.5 | 85.5 | 9 | 75 | ||||||
| 130 | 115 | 95 | 10 | 75 | ||||||
| 143 | 126.5 | 104.5 | 11 | 90 | ||||||
| 156 | 138 | 114 | 12 | 90 | ||||||
| 300LJC185-12 | 130 185 235 | 27 | 24 | 18.9 | 2 | 18.5 | 14 | 1460 | 80 | 295 |
| 40 | 36 | 28.4 | 3 | 30 | ||||||
| 54 | 48 | 37.8 | 4 | 37 | ||||||
| 67 | 60 | 47.2 | 5 | 45 | ||||||
| 81 | 72 | 56.7 | 6 | 55 | ||||||
| 94 | 84 | 66 | 7 | 75 | ||||||
| 108 | 96 | 75.6 | 8 | 75 | ||||||
| 121 | 108 | 85 | 9 | 90 | ||||||
| 135 | 120 | 94.5 | 10 | 90 | ||||||
| 300LJC220-13.5 | 154 220 264 | 29 | 27 | 22 | 2 | 32 | 12 | 1460 | 80 | 295 |
| 44 | 40.5 | 34 | 3 | 27 | ||||||
| 59 | 54 | 45 | 4 | 45 | ||||||
| 74 | 67.5 | 57 | 5 | 55 | ||||||
| 89 | 81 | 68 | 6 | 75 | ||||||
| 104 | 94.5 | 79 | 7 | 90 | ||||||
| 119 | 108 | 91 | 8 | 90 | ||||||
| 350LJC300-15 | 230 300 370 | 35 | 30 | 23 | 2 | 37 | 12 | 1460 | 80 | 346 |
| 52.5 | 45 | 34.5 | 3 | 55 | ||||||
| 70 | 60 | 46 | 4 | 75 | ||||||
| 87.5 | 75 | 57.5 | 5 | 90 | ||||||
| 105 | 90 | 69 | 6 | 110 | ||||||
| 122.5 | 105 | 80.5 | 7 | 132 | ||||||
| 350LJC370-16 | 270 370 460 | 19 | 16 | 11.5 | 1 | 30 | 12 | 1460 | 80 | 346 |
| 38 | 32 | 23 | 2 | 55 | ||||||
| 57 | 48 | 34.5 | 3 | 75 | ||||||
| 76 | 64 | 46 | 4 | 90 | ||||||
| 95 | 80 | 57.5 | 5 | 110 | ||||||
| 114 | 96 | 69 | 6 | 132 | ||||||
| 350LJC400-18 | 280 400 480 | 20.8 | 18 | 14 | 1 | 37 | 12 | 1460 | 80 | 346 |
| 41 | 36 | 29 | 2 | 55 | ||||||
| 62 | 54 | 43 | 3 | 90 | ||||||
| 83 | 72 | 58 | 4 | 110 | ||||||
| 104 | 90 | 73 | 5 | 132 | ||||||
| 400LJC450-30 | 290 450 540 | 35 | 30 | 25 | 1 | 55 | 22 | 1475 | 80 | 430 |
| 70 | 60 | 50 | 2 | 110 | ||||||
| 105 | 90 | 75 | 3 | 150 | ||||||
| 140 | 120 | 100 | 4 | 200 | ||||||
| 175 | 150 | 125 | 5 | 250 | ||||||
| 400LJC550-27 | 400 550 850 | 29 | 27 | 17.5 | 1 | 55 | 20 | 1475 | 81 | 430 |
| 58 | 54 | 35 | 2 | 110 | ||||||
| 87 | 81 | 52.5 | 3 | 180 | ||||||
| 116 | 108 | 70 | 4 | 225 | ||||||
| 145 | 135 | 87.5 | 5 | 280 | ||||||
| 450LJC650-32 | 520 650 850 | 35 | 32 | 22 | 1 | 90 | 20 | 1475 | 80 | 520 |
| 70 | 64 | 44 | 2 | 180 | ||||||
| 105 | 96 | 66 | 3 | 250 | ||||||
| 140 | 128 | 88 | 4 | 350 | ||||||
| 175 | 160 | 110 | 5 | 400 | ||||||
| 450LJC900-30 | 600 900 1100 | 34 | 30 | 24 | 1 | 110 | 20 | 1475 | 82 | 520 |
| 68 | 60 | 48 | 2 | 225 | ||||||
| 102 | 90 | 72 | 3 | 315 | ||||||
| 136 | 120 | 96 | 4 | 400 | ||||||
| 170 | 150 | 120 | 5 | 520 | ||||||
| 500LJC1000-29 | 790 1000 1300 | 33 | 29 | 21 | 1 | 110 | 20 | 1475 | 83 | 600 |
| 66 | 58 | 42 | 2 | 225 | ||||||
| 99 | 87 | 63 | 3 | 350 | ||||||
| 132 | 116 | 84 | 4 | 450 | ||||||
| 500LJC1250-30 | 800 1250 1750 | 36 | 30 | 18.5 | 1 | 150 | 17 | 1475 | 84 | 600 |
| 72 | 60 | 37 | 2 | 280 | ||||||
| 108 | 90 | 55.5 | 3 | 400 | ||||||
| 144 | 120 | 74 | 4 | 560 | ||||||
| 500LJC2000-31 | 1500 2000 2400 | 36 | 31 | 25 | 1 | 250 | 22 | 1475 | 80 | 670 |
