CQF PP Plastic Magnetic Pump
US$ 200 - 1000
MOQ: 1 Unit
Key Specifications
Get Latest Price
Brand Name:
kenshine-pump
Place of Origin:
China
Model Number:
32CQ-25
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
7 days
Related Products
-
HCLF no Leakage Vertical Fluorine Lined Pipeline Magnetic PumpUS$ 300 - 6000MOQ: 1 Set -
CQB Stainless Steel no Leakage Magnetic Drive PumpUS$ 650 - 8000MOQ: 1 Set
-
CQ Stainless Steel Magnetic Drive Pump no LeakageUS$ 300 - 6000MOQ: 1 Set
-
CQF Engineering Plastic Magnetic PumpUS$ 180 - 2000MOQ: 1 Set
-
CQ Magnetic Centrifugal Transfer PumpUS$ 320 - 2000MOQ: 1 Set
Brand Name
kenshine-pump
Place of Origin
China
Model Number
32CQ-25
Application
Other, chemical liquids pump
Fuel
Other, electric motor
Power
Electric
Usage
Other, chemical acid,alkali,solvent
Theory
Centrifugal Pump
Standard or Nonstandard
Standard
Structure
Single-stage Pump
Pressure
Low Pressure
CQF engineering plastic magnetic drive pump:
CQF polypropylene plastic magnetic pump is mainly made of reinforced PP and all the wet parts which contact with liquids adopt injection mould with resistance. CQF PP plastic magnetic drive pump is used for most organic and inorganic acid, alkali and solvent etc. The pump is applicable for being exposed outdoor with good anticorrosive performance and stress corrosion cracking.
The pump inlet and outlet can be pipe connection or flange connection and has the features of small volume, light weight, fine corrosion resistance etc.
| Model | Inlet(mm) | outlet(mm) | Flow(m3/h) | Head(m) | NPSHr(m) | power(kw) | speed(rpm) | voltage(v) |
| 14CQF-5 | pipe 24 | pipe 16 | 1.2 | 5 | 7 | 0.12 | 2900 | 220/380 |
| 16CQF-8 | pipe 24 | pipe 16 | 1.8 | 8 | 6 | 0.12 | 2900 | 220/380 |
| 20CQF-12 | pipe 26 | pipe 18 | 3 | 12 | 6 | 0.37 | 2900 | 220/380 |
| 25CQF-15 | 25 | 20 | 6.6 | 15 | 5 | 1.1 | 2900 | 380 |
| 32CQF-15 | 32 | 25 | 6.6 | 15 | 6 | 1.1 | 2900 | 380 |
| 32CQF-25 | 32 | 25 | 6.6 | 25 | 5.5 | 1.1 | 2900 | 380 |
| 40CQF-20 | 40 | 32 | 10.8 | 20 | 3.5 | 2.2 | 2900 | 380 |
