Vertical Vacuum Insulating Oil Purifier, movable transformer oil filtering machine, on-the-spot single stage transformer oil purifier
- 550 Set / Sets per Month
- Shanghai, Qingdao, Chongqing, Guangzhou, Shenzhen
- T/T L/C Other
- 7 days
- ShuoBao stainless steel filter 304/316 with PP filter bag for water pretreatment system
- ShuoBao water filter housing stainless high flow for water pretreatment system
- ShuoBao 1 micron water filter with liquid filter bag for PCB
- Shuobao all size stainless water filter housing for water filtration
- Shuobao International Standard Stainless Steel cartridge filter 304/316
- SUS 304 cartridge filter High-Temperature Resistant Steel
Product Details
Brand Name: | HOPU | Place of Origin: | China | Model Number: | ZY |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Applications:
ZY Series high vacuum transformer oil purifier is applied to purify various unqualified or used insulation oils such as aging transformer oil, mutual inductor oil, switch oil, capacitor oil, cable oil, circuit breaker oil etc. It removes free or soluble water, gases, particulate matters etc, and improves oil dielectric strength. Also it can fill the insulating oil into the transformers.
More models for ZY Series:
ZY Portable Vacuum Insulating Oil Purifier
ZY-A PLC fully automatic vacuum transformer oil purifier
ZY-M Outdoor mobile vacuum transformer oil purifier (equipped with trailer and enclosure)
ZY-W fully enclosed vacuum insulating oil purifier (equipped with enclosure)
ZY-S trailer equipped open type vacuum insulating oil purifier
ZY-Ex explosion-proof vacuum transformer oil purifier
Features:
1. ZY machine is small, highly efficient and operated easily. And it can be live operated with electricity, carry out vacuum oiling power equipment and dry moisture of power equipment.
2. Duplex-Stereo film evaporation technology, combined with unique and advanced dewatering, degassing components, it can rapidly and effectively separate water, gas from oil.
3. Efficient electric heating system, heating uniformity, less power consumption, safe and reliable.
4. Double-infrared liquid level sensor, pressure protective system to ensure the machine operation easy and safely.
5. Adopts interlocked protective system which connect oil pump, heater and liquid level sensor to avoid blank heating, blank pumping, oil leak or electricity leak. If there is any fault, machine will power off automatically.
6. Can work with our regeneration device to decolor (and remove acid, oxide, free carbon) if it is required.
Advantages:
This machine adopts highly effective vacuum and advanced stereo-evaporation technology which enable highly effective removal of water, gas and impurities without poweroff, shutdown of machine or change of oil which allows transformers running with energized.
Technical Parameters:
Parameters | Unit | ZY-6 | ZY-10 | ZY-20 | ZY-30 | ZY-50 | ZY-100 | ZY-150 | ZY-200 | ZY-300 | |
Flow rate | L/h | 360 | 600 | 1200 | 1800 | 3000 | 6000 | 9000 | 12000 | 18000 | |
Vacuum degree | MPa | -0.06~-0.095 | |||||||||
Working pressure | MPa | ≤0.3 | ≤0.4 | ≤0.4 | ≤0.4 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | ≤0.5 | |
Temperature range | °C | 20 ~ 80 | |||||||||
Continuous working | H | 150 | |||||||||
Power supply | Three phase,50HZ ,380V(or as per customer requirement) | ||||||||||
Working noise | dB(A) | 60 | 61 | 63 | 70 | 70 | 75 | 70 | 70 | 70 | |
Heating power | kW | 9 | 11 | 13 | 15 | 30 | 48 | 58 | 70 | 85 | |
Total power | kW | 9.7 | 12.5 | 14.5 | 16.5 | 33.5 | 53 | 65 | 76 | 94 | |
Oil inlet/outlet | mm | φ20 | 25 | φ25 | φ25 | φ32 | φ42 | φ50 | φ50 | φ60 | |
Weight | Kg | 150 | 230 | 250 | 270 | 300 | 500 | 700 | 900 | 1100 | |
Size | L | mm | 970 | 1050 | 1100 | 1150 | 1200 | 1600 | 1600 | 1800 | 1900 |
W | mm | 630 | 750 | 850 | 900 | 950 | 1000 | 1100 | 1200 | 1200 | |
H | mm | 900 | 1300 | 1400 | 1450 | 1500 | 1800 | 1800 | 1900 | 1900 |
Guarantee Value
Item | Guarantee indexes |
Moisture content | ≤5PPM |
Impurity size | ≤1 micron |
Gas content | ≤0.1% |
Breakdown voltage | ≥65 |
