Application:
This purifier is widely used in power station, power plants, transformer station, petroleum, chemistry, metallurgical and national defense industries. It is designed for filtering water and impurities of transformer oil, turbine oil, hydraulic oil and other oils. It adopts filter papers as filtering substance. The client's requirements can be met by adopting automatic fluid level control and automatic pressure alarm.
Series LY specially explosion proof vacuum oil purification is suitable for purifying of oil such as lubricating oil, heavy fuel oil, turbine oil, hydraulic oil and refrigerator oil used in the flammable and explosive environment in the fields of petrochemical industry, petroleum industry, chemical industry, coal industry, metallurgical industry, power industry, etc.
The equipment is applied with complete explosion proof measure based on LY series, high effective vacuum oil purifier. It can effectively remove harmful substance in poor quality, such as water, mechanical impurity, and gas till the oil meets standard requirement. The explosion proof class are ExdBT4 and ExdCT4 respectively. It can meet requirement in various dangerous environments.
Features
1. Mainly filtering impurities of transformer oil, turbine oil, engine oil, diesel oil, kerosene, aviation hydraulic oil.
2. It also can be used for filtering edible oil while using stainless steel.
3. Portable,light weight and easy to operate.
Advantages:
LY Series oil purifier is characterized by simple structure,easy operation,low cost,etc.This machine is very efficiency to Filtering water and impurities from transformer oil, turbine oil, engine oil, diesel oil, kerosene, aviation hydraulic oil as well as cooking oil which made by stainless steel.
Technical Parameter List:
Model |
Unit |
LY-50 |
LY-100 |
LY-150 |
LY-200 |
LY-300 |
LY-400 |
LY-500 |
|
Flow |
L/H |
3000 |
6000 |
9000 |
12000 |
18000 |
24000 |
30000 |
|
Working Pressure |
MPa |
≤0.3 |
|||||||
Filtration Area |
m2 |
0.5 |
1.3 |
1.9 |
2.5 |
3.2 |
6 |
6.5 |
|
Board Frame Size |
mm |
180×180 |
280×280 |
||||||
Press Manner |
Screw Manually |
||||||||
Working Power Supply |
V |
380V/50Hz(or at user’s option) |
|||||||
Motor Power |
Kw |
1.5 |
1.5 |
2.2 |
2.2 |
5.5 |
7.5 |
7.5 |
|
Pipeline Diameter |
mm |
32 |
40 |
45 |
45 |
60 |
80 |
80 |
|
Filter Size |
mm |
190×190 |
290×290 |
||||||
Overall Dimensions |
Length |
mm |
600 |
750 |
750 |
750 |
950 |
1050 |
1100 |
Width |
mm |
370 |
470 |
470 |
470 |
600 |
1200 |
1250 |
|
Height |
mm |
800 |
1000 |
1050 |
1050 |
1100 |
1300 |
1350 |
|
Net Weight |
kg |
180 |
240 |
410 |
500 |
600 |
700 |
750 |
|
