800L840L1000l CHLORINEgas REFRIGERANT GAS Cylinder With Flange &without With LR,BV CERTIFICATE
US$ 200 - 1000
MOQ: 5 Pieces
Key Specifications
Get Latest Price
Brand Name:
lanyi
Place of Origin:
China
Model Number:
926L,1000L 1000KG
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai PORT
Delivery Detail:
30 days
Related Products
-
CHLORINE GAS REFRIGERANT GAS Cylinder AMMONIA GAS With Flange &without With LR,BV CERTIFICATEUS$ 200 - 1000MOQ: 5 Pieces -
HIGH QUALITY CHLORINE GAS REFRIGERANT GAS Cylinder AMMONIA GAS With Flange &without With LR,BV CERTIFICATEUS$ 200 - 1000MOQ: 5 Pieces
-
1000kg840L CHLORINE REFRIGERANT GAS Cylinder With Flange &without With LR,BV CERTIFICATEUS$ 200 - 1000MOQ: 5 Pieces
-
1000kg840L CHLORINE ,AMMONIA ,REFRIGERANT GAS Cylinder With Flange &without With LR,BV CERTIFICATEUS$ 200 - 1000MOQ: 5 Pieces
-
1000kg840L CHLORINE REFRIGERANT GAS Cylinder With Flange &without With LR,BV CERTIFICATEUS$ 200 - 1000MOQ: 5 Pieces
Brand Name
lanyi
Place of Origin
China
Model Number
926L,1000L 1000KG
Power
Hydraulic
Standard or Nonstandard
Standard
Structure
General Cylinder
Shaft Diameter
800mm
Maximum Stroke
1000kg
Body Material
Steel
Product Description
Empty Liquid chlorine,refrigerant gas ,ammonia gas and other industry gas cylinder is made of high quality steel, which capacity has100L, 400L, 800L, 840L,926L,1000L with GB5100 standard, whatsapp08613775295733 and its specification as follows:
| Medium | Liquid Chlorine ,refrigerant gas ,ammonia gas Cylinder | ||
| Nominal capacity | 400 L | 800 L | 926 L |
| Nominal working pressure | 2 Mpa | 2-2.1 Mpa | 2 Mpa |
| Hydraulic test pressure | 3 Mpa | 3-4.5 Mpa | 3 Mpa |
| Working temperature | -40-60 ºC | -40~60 ºC | -40-60 ºC |
| Design Wall thickness | 3.8 mm | 5.1 mm | 5.1 mm |
| Nominal wall thickness | 6-8 mm | 10-12 mm | 10 mm |
| Filling ratio (kg/L) | 1.25 | 1.25 | 1.25 |
| Max Filling weight | 500 KGS | 1000 KGS | 1150 KGS |
| Design working life | 12 Year | 12 Year | 12 Year |
| Valve | QF-10 | QF-10 | QF-10 |
| Out thread of valve | G3/4 | G 3/4 | G3/4 |
| Height of body | 1800 mm | 2000 mm | 2255 mm |
| Weight | 250 KGS | 445 KGS | 512 KGS |
