MS303is a Fully Automatic Stretch Wrapper. It’s an ideal wrapper to integrate into a palletizing line to achieve automatic pallet packaging. The wrapper automatically pick up a loaded pallet from in-feed conveyor, wrap it and conveyor the load to out-feed conveyor. These machines are designed for low to medium-duty wrapping applications. The wrapping machines are available in different configurations, with the possibility of 90° pallet in-feed and out-feed conveyors.
Technical Specification
Model MS303
Diameter of turntable 2000mm
Packing size L(500-1200)*W(500-1200)*H2000mm(can customized2200/2400/2800/3000mm)
Control system Siemens PLC
Loading 2000kg
Voltage 220V-415V 3Ph
Power 50/60HZ 1.95KW
Air pressure 0.4-0.7MPa
Efficiency 25loads/hour
Speed 15rpm/min(adjustment)
Pressure of top plate 25kg can be adjustment
Machine size L2570mm*2000mm*H2540mm
Packing size L2620mm*W2200mm*H2590mm
N.W 1200kg
G.W 1400kg
H.S 84224000
Our Services
1.OEM / ODM service is avaliable,and provide technology supporting in products for we are in 10years exporting experience.
2.Provide our factory certificate TUV,Assembe supplier.
3.Provide you Quality Control in processing line.
4.Provide you freight forwaring information to save cost.
5.After sales service.Our Services
1.OEM / ODM service is avaliable,and provide technology supporting in products for we are in 10years exporting experience.
2.Provide our factory certificate TUV,Assembe supplier.
3.Provide you Quality Control in processing line.
4.Provide you freight forwaring information to save cost.
5.After sales service.
