CNC High Accuracy HSS Saw Blade Grinding Machine

CNC High Accuracy HSS Saw Blade Grinding Machine

Features:

JC-500 CBN.CNC full automatic computer numerical control circular saw machine is made by the innovated technology; it is full automatic CNC processing center controlled and is with precise structure, its speed is faster than other equipments of the same rank.
JC-500, the CNC saw blade grinder, its foundation is made of spheroid graphite ductile iron FCD-45, that is with good vibration state damping and well movement performance, it may improve the finishing, and its thermal conductivity is low, so that the affection that caused by the environmental temperature change is little, and it does not distort. Therefore, it can maintain the stability of the machine and promote the precision and the service life.
JC-500 CBN saw blade grinder is mainly suitable for the customer such as pipe & tube machinery manufacturer, pipe making manufacturer, pipe cutter manufacturer, saw blade manufacturer, and saw blade sharpening manufacturer, furniture manufacturer, bicycle manufacturer and automobile manufacturer.
Novel design and perfect streamline enhance JC-500 CBN on its unique outstanding style. There is a fine view to watch the working situation from the large window, and it is also very convenient to open the arc gate to replace the saw blade.
JC-500 CNC saw blade grinder is a three axle servo-control CNC saw blade grinder; the outer diameter, the number of teeth (gears), the attrition quantity, the angle of cutting, the back clearance cutting angle can be automatically set up and controlled.
The CNC saw blade grinder adapts 10.4” TFT-LCD monitor; it is outfitted with the dialogue type operation screen, the machine will automatically finish the gridding job only by inputting simple data.

Advanced software design: The outer diameter, the number of teeth, the tooth depth, cutting angle, back clearance angle, feeding rate and the grinding wheel rotation speed can be all numerically input. Easy operation, even if you are not the senior technician.
The functional CNC controller may provide you the ideal processing performance according to the majority demands. Ultra strong memory storing function: it can be inputted 9999 set of saw blade attrition parameter, it will show you the saw blade records on the screen within few seconds, it will save a lot of time on reset.
The JC-500CNC series of circular cold saw blade sharpener is the perfect complement for the customer who has multiple automatic or semi-automatic CNC cold saw blades that for higher production runs.
Bringing cold saw blade sharpening in house allows the manufacturer to reduce sharpening costs allowing for quick turnarounds (compared to outsourcing cold saw blade sharpening).
By eliminating time consuming adjustments, the productivity is increased on account of the simplicity designed into our sharpeners. The manufacturer or fabricator can sharpen the saw blades economically and quickly right in their own shop. Furthermore, It also increases efficiency due to the saw blades can be sharpened to the exact specifications without delay.

Parameters:

Configuration:

Teeth Type :

HSS Saw Blade :

Machine Photo :

 Certificate :

       Company Profiles :

with decades hard  work  and  accumulated  experiences,  We have  acquired  fourty  invention

patent,Utility model and appearance patent.Meanwhile, We  have  passed  ISO9001:2008 quality system certificate, Government-issued  Guangdong  Province  private technology enterprises, high-

tech  enterprises, private enterprises and other honors.

The products  include Super hard metal bar cold saw machine series, Chipless  metal pipes circular saw machine series,Copper aluminum non-ferrous high-speed precision circular saw machine series,Metal pipe/bar end chamfer machine series,Circular saw blade sharpening machine series,Automatic pipe bending and forming Machine series , Six categories eighty models , Also provide customized complex process

Machine , all kinds of circular saw blade . Wide  Application  range  contains Nautical

aviation and aerospace industry, military industry, high-speed rail and rail transportation

industry, auto industry, precision parts, medical and fitness equipment industry, mechanical and electrical and electronic industry, lighting and furniture decoration forty industries .
