Hydraulic Metal Pipe Notching Machine
- ShenZhen/GuangZhou
- T/T Credit Card
You May Like
-
CNC Iron Square/Rectangle Metal Pipe Punching and Cutting Machine
-
Iron Tube Hydraulic Automatic Notching Machine
-
NC Hydraulic Full Automatic Steel Pipe Notching Machine
-
Hydraulic Steel Pipe Notching And Cutting Machine
-
Stainless Steel/Carbon Steel Pipe Punching Machine for Scalfolding
-
Hydraulic Semi-Automatic Pipe Punching Machine
Product Details
| Brand Name | Chine Chern | Model Number | JC-CKJ-100-1 |
Product Description
Hydraulic Metal Pipe Notching Machine
Features :
1. Fully automatic pipe punching machine applied in shelf, guardrail ,round pipe ,square pipe .
2.Pipe size: 80mm & 40*80mm,Stainless steel pipe wall thickness: Max 1.5mm.
3.We can change different mould for different shapes.Hydraulic system controlls clamping ,up and down.the location of work piece is controlled by servo motor (X axis),the whole machine adopts microcomputer ,we can set the parameters and change the operation by touch screen panel.
4.We can punch holes for same hole distance and different hole distance as per request .
5. The punching hole is not be deformation,Smooth surface
6. Servo Motor feed is more accurate.
7. Changing Mould is Simple.
Parameters:
| Item | JC-CKJ-100-1 | ||||||
| Max pipe specification | 80/80mm×80mm | ||||||
| Max process wall thickness | Aluminum:2mm-3mm | ||||||
| Punching hole diameter | 5mm-25mm(Customise as per drawing ) | ||||||
| Max feeding length once | 1500mm | ||||||
| Continously process hole quantity | Not limited | ||||||
| Max work piece length | 6000mm | ||||||
| Work efficiency | 2-3Seconds/Hole | ||||||
| Max feeding speed | 1000mm/seconds | ||||||
| Linear Motion accuracy(Servo Motor feed ) | ±0.05mm | ||||||
| Operation mode | Automatic/Manual/Touch switch | ||||||
| Load/Unload Material mode | Manual | ||||||
| Machine weight | 900kg | ||||||
| Power supply | 380° ±10V ,50HZ | ||||||
| Voltage | 3-phase 380V 50HZ | ||||||
| Total power | 6.5KW | ||||||
| Max work pressure | 140Mpa | ||||||
| hydro-cylinder diameter | 100mm×1 | ||||||
| Machine dimension | L2800×W1200×H1850mm(reference) | ||||||
Hole Shape:
Machine Picture :
