P-100 Automatic Sand Belt Stainless Steel Pipe Tube Polishing Machine
- T/T Credit Card
You May Like
-
P-100 Automatic Grinding Belt Curved Pipe Polishing Machine for Max Stainless Steel Pipe 110mm
-
P-100 Abrasive Belt Stainless Steel Curved Pipe Surface Sanding Polishing Machine
-
PH-125CNC Automatic Hydraulic Square Pipe Hole Punching Machine With Servo Feeding
-
PH-125CNC Automatic Hydraulic CNC Tube Hole Punching Machine With Servo Feeding
-
Underwater Pneumatic Welded Pipe Gas-tight Testing Equipment for Inside Pressure
-
Automatic Pneumatic Pressure Pipe Inside Testing Machine With Auto Pipe Loading Unloading
Product Details
| Brand Name | CARE |
Product Description
P-100 Automatic sand belt stainless steel pipe tube polishing machine
Main features
1) Belt finishing machines for round or oval tube, straight or curved.
2) RT Planetary system: soft and perfect finishing in one step with great flexibility.
3) Automatic feeding with 2 units of 4 driving rollers.
4) Wide range of finishes with speed inverters on abrasive belts and feeding units.
5) Ergonomy, strength and high quality construction.
6) Innovative methods, greater productivity and improved quality.
Technical parameter
Polishing pipe range | 10-110mm |
Main power | 4Kw |
Grinding belt motor power | 2.2Kw |
Grinding belt motor rotating speed | 1200-3300Rpm |
Grinding belt speed | 7.8-18m/s |
Main wheel motor | 1.5Kw |
Grinding belt size | 940x50mm |
Voltage | 380V/50Hz/3P |
Electric current | <20A |
Feeding speed | 0.7-4m/Minute |
Feeding motor | 0.12KwX2 |
Machine photo
Main parts
Pipe samples
