China Under Water Pipe Pneumatic Pressure Tester Machine
US$ 30,000 - 40,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
CARE
Place of Origin:
Jiangsu, China
Model Number:
ZQ-1001 Pipe pneumatic Pressure Tester Machine
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Automatic Steel Pipe Inside Wall Polishing Machine With Special UseUS$ 30,000 - 40,000MOQ: 1 Set -
Automatic Stainless Steel Tube Inside Wall Polishing Machine With 2 StationsUS$ 30,000 - 40,000MOQ: 1 Set
-
Automatic Tube and Pipe Inside Surface Polishing Machine With Special DesignUS$ 30,000 - 40,000MOQ: 1 Set
-
Auto Metal Saw Blade Grinder Machine for Saw Blade Diameter From 50mm to 450mmUS$ 1,800 - 1,800MOQ: 1
-
Automatic Metal Saw Blade Sharpening Machine for Saw Blade Diameter From 50mm to 450mmUS$ 1,800 - 1,800MOQ: 1
Brand Name
CARE
Place of Origin
Jiangsu, China
Model Number
ZQ-1001 Pipe pneumatic Pressure Tester Machine
After-sales Service Provided
Engineers available to service machinery overseas
China Under water Pipe pneumatic Pressure Tester Machine
The machine is made to test the inside of steel tube/pipe pressure. It is using water to inspect whether the steel has been welded properly or not or can be figure out the steel is flawed or not and also what will be the maximum pressure that can sustain for the stainless steel tube/pipe to reach consumer requirement.
| Main specification | ||||||
| 1. Test Tube Diameter: 12.7 ~ 76.2mm | ||||||
| 2. Test Tube Length: 6.1 m ± 1 0mm(Can customize the machine according to tube length) | ||||||
| 3. Detection speed: Two station 1pc/ 2 min | ||||||
| Three-position 1pc / 1.5 min | ||||||
| 4. Test pressure: 0.69 MPa; required to provide more than 0. 69 MPa external gas source, the device itself without booster function. | ||||||
| 5. Sealing way: outer radial seal | ||||||
| 6. Pneumatic clamping, V-shaped clamp | ||||||
| 7. Underwater airtight machine: 1 9 ~ 76.2mm average double station Or all three stations. | ||||||
| Working process | ||||||
| According to the unit test sequence and function, the unit can be divided into fixed and try to press the seat, stand activities, pneumatic unit and electronic control devices. By both sides finished steel tube was sealed and joined the clean air and sank sink pressurized to keep the pressure testing standards after a period of time to verify that there is relief, leaks, cracks and other defects. | ||||||
| Production capacity | ||||||
| Diameter | Test length | Detection speed | Production time(h) | Annual (branch) | ||
| 1 9~76.2mm | Each 6 m | 1/2 min | 7000 | 210 000 | ||
| 19~76.2mm | Each 6 m | 1 / 1.5 min | 7000 | 280 000 | ||
| Machine photo | ||||||
Main parts
