Aluminium Window Door Corner Connector Cutting Machine
- Qingdao Port
- T/T Credit Card
You May Like
-
Aluminum Window Frame Assembly Machine
-
Aluminium Crimper for Window and Door
-
Aluminum Profile Any Angle Single Head Mitre Saw/ Single Head Cutting Saw Machine
-
Aluminum Window Door Four Crimping Machine
-
Aluminum Profile Cutting Machine/Aluminium Profiles Schneider System Double Mitre Saw
-
Aluminium Window Making Machine/ Aluminium Profile Four Heads Crimping Machine / Cnc Machine for Aluminium Windows
Product Details
| Brand Name | Parker |
Product Description
Aluminum Window Corner Connector Profile Cuting machine
Features:
For aluminium corner key cutting.
High efficiency, high precision, for large scale produce.
Automatically cutting and counting.
When power is turned off suddenly, clamping devices keep fixing profiles to protect wokers and machine.
Safe guards get down during cutting, arise after cutting.
Automatically feeding by servo motor driving ball screw.
Imported high quality hard metal saw blade-WEMARO; servo motor and PLC-OMRON; touch screen-Eview; squar guide rail-HIWIN.
Parameter:
| Voltage: | 380V 50HZ |
| Power: | 2.6KW |
| Air pressure: | 0.5-0.8MPa |
| Blade specification: | Φ500×Φ30×4.4Z=120 (standard size) |
| Blade rotate speed: | 2840rpm |
| Cutting length: | Max700mm Min7mm |
| Cutting width: | 140mm |
| Cutting height: | 140mm |
| Cutting angle: | 90° |
| Repeat locating length error: | ±0.2mm |
| Surface plainness: | ±4′ |
| Overall dimension: | 1500mm*1600mm*1600mm |
PARKER IS DEVELOPING WITH THE WORLD.
Parker was founded in 2003, since the entry into the window door curtain wall machinery manufacturing field, peck with the best team and most stringent manufacturing standards, has been committed to the global supply of machinery and the best service. Today, with more than 300 employees, Parker Industrial Park covers an area of 70000 square meter, Parker has become Chinese and even the world's window door curtain wall and insulating glass high-end machinery manufacturing base.
| | |
Automatic Aluminum Profile Cutting Machine For Window Door | A8-500 3 axis CNC any angle aluminum profile cutting saw | Aluminum Corner Key Cutting Machine |
