Window Door Machine CNC Control Double Mitre Saw

Name: Window Door Machine CNC Control Double Mitre Saw
Brand: PARKER
Availability: InStock

FOB Price

US$ 40,000 - 40,000

1 (Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

PARKER

CNC Control Double Mitre Saw

Model: LJZ2-CNC-E500

Feature:

ØIt has large cutting range, hi-efficiency and perfect safe guards. It is suitable for large scale production.
ØThe structure is strong and of excellent rigidity and reliability, so it is impossible to be out of shape.
ØThe hi-quality imported special hard-metal saw makes cutting more precision.
ØThe main shaft with hi-precision makes the saw operating stable and the cutting surface smooth.
ØThe gas-liquid damping cylinder realizes smooth feeding and steady moving.
ØThe imported guide rails and the linear motion pair can realize high precision and accurate location.
ØThe two-way location-and-clamping features high precision and steadiness.
ØThe well-sealed safeguard of saw blade prevents the cutting bits from flowing everywhere.

Parameter:

ØVoltage:	380V 50HZ
ØPower:	5.9KW
ØAir pressure:	0.5-0.8MPa
ØAir consumption:	200L/min
ØBlade specification:	500304.4mm (standard size)
ØCutting length:	400mm-4200mm
ØCutting width:	Max.135mm
ØCutting height:	Max.300mm
ØCutting angle:	45° 67.5° 90°
ØRepeat locating length error:	+/-0.2mm
ØCutting angle error:	+/-4”
ØSurface plainness:	+/-0.1mm
ØSurface roughness:	Ra12.5um
ØOverall dimension:	5500mmX1750mmX1990mm
