HYBRID SC 910 Chemiluminescence System
- shenzhen
- T/T Credit Card
You May Like
Product Details
Brand Name | SHANFU-Y | Place of Origin | Shaanxi, China | |
Model Number | HYBRID SC 910 |
Product Description
HYBRID SC 910 Chemiluminescence System
Introduction
910 is the entrylevel chemiluminescence imaging, compatible general fluorescence gel documentation system
and electrophoretic analysis, with zoom lens. Applies to products which the time of exposure is more than 2 minutes during traditional tabletting process. At the same time it can observe chemiluminescence and get clear fluorescence gel documentation.
Feature
1ChemShot 910 has seal design, guarantee of positive confinement of darkroom, applies to development with
time exposure in low-level light source.
2 Applies to products which the time of exposure is more than 2 minutes during traditional tabletting process.
3 ChemShot 910 uses imported 2/3 big size CCD which can cool till -35℃, that guarantees weak chemiluminescence capture.
4 Six-Position Motorized filter wheel will help you to reserve the space with more applications.
5 It kept back the design of UV transillumination, so now you can make chemiluminescence and simple gel
documentation at the same time.
6 Software for ChemShot gel documentation can take pictures and analyze DNA/RNA, protein electrophoresis, fluorescence and chemiluminescence and Hybond membrane`s images, clone counting, autoradiography and images of dot blot hybridization;
it automatically recognizes stripes and borders around, automatically creates curve graphs with peak`s values and data sheets; counts molecular weight, percentage
and content, also creates database of molecular weight; it also has a function of image database.
7 Scope of application:used for chemiluminescence of nuclear acid glue, albumin glue, western blot with
various kinds of coloring agent, Hybond membrane images etc.
8 This product has passed the accreditation of CE certification.
Technical Parameter
Camera:Imported high resolution low-light digital refrigeration CCD
CCD size:8,8mm*6.6mm
Cooling power: -60℃, 3 stage semiconductor
Effective resolution (pixels m) :1960*1460 2.8
Pixel Density:16bit
Pixel Size:4.54μm*4.54μm
Sensitivity: 20pg of double-stranded DNA
Zoom lens (motor driven):Japanese imported 6x motorized zoom F1.0, 2/3 inch high caliber penetrating lens
Illumination: Trans-UV, Trans-White, Epi White
Excitation light source: Trans-UV 312nm, Trans-Cold White, Epi White LED Lights, Epi-UV are optional
Filter: Standard 590 screw-type filter with coating
Filter options: 537nm red filter, 460nm blue filter, 699nm filter
Control mode:you can change focus, diaphragm, zoom and light source with front-panel control or computer
Observing: You can make a preview of gel images on your computer in actual time
Transmission plane:UV: 21*26cm, White light: 20*28cm
Size: 430*430*620mm
Dear customer, We ,Xi’an Yima Opto-electrical Technology Com.,Ltd. is an integrated economic entity of R&D,manufacturing and trading with over 20 years of history . Our business scope covers various fields such as biochemical analysis,environmental protection,industrial testing, bioscience,medical apparatus and instruments,internet technology and some frontier science. Through a long-time development,we own a national resources system of various professional talents , abundant supply for various components &parts and special materials, full producing &processing equipments , strong Technological standardization and a complete quality assurance system. If you need OEM or ODM in manufacturing ,scientific research , market development and or you want to build your own brand in your country, it’s our honor to cooperate with you.In this way ,we have developed many products for our customers from the USA, Europe and South Africa and got good feedback on Alibaba We firmly believe that science and technology is no boundaries Our mission is to make every effort to contribute to all humanity. |
