Semi-auto Flat Bed Creasing And Die Cutting Machine
- 20 Set / Sets per Month
- TIANJIN
- T/T L/C
- 45 days
- Leizhan Disc sludge thickener for paper pulp making production line
- 2013HOT SELL Stainless steel structure Disc thickener for paper pulp making production line
- Disc pulp filter machine of fluting and kraft paper production line
- Leizhan waste paper recycle equipment ZNP series disc thickener/paper processing equipment/paper pulp machinery
- disc thickener/paper pulp industrial use
- disc thickener used for washing and thickening/paper making industry
Product Details
Brand Name: | HRB PACK | Place of Origin: | China | Model Number: | MY-1200 |
Certification: | CE ISO | Type: | Die-cutting Machine | After-sales Service Provided: | Engineers available to service machinery overseas |
Warranty: | 1 Year | Weight: | 13T | Dimension(L*W*H): | 4200*2200*2250mm |
Condition: | New | Voltage: | 220V 380V 440V | Power(W): | 11KW |
Computerized: | Yes |
Product Description
Model | MY-1200 | MY-1300 | MY-1500 | MY-1650 |
Max.Paper Size | 1230×850mm | 1320×940mm | 1510×1120mm | 1670×1250mm |
Min.Paper Size | 350×450mm | 400×500mm | 450×550mm | 500×550mm |
Max.Die-cutting Size | 1210×830mm | 1300×920mm | 1490×1100mm | 1650×1200mm |
The minimum size in mouth | 8 | 8 | 8 | 8 |
Max.Die-cutting Pressure | 300n/cm2 | 300n/cm2 | 300n/cm2 | 300n/cm2 |
Carboard | 200-2000g/m2 | 200-2000g/m2 | 200-2000g/m2 | 200-2000g/m2 |
Corrugated paper | 8mm(max.thickness) | 8mm(max.thickness) | 8mm(max.thickness) | 8mm(max.thickness) |
Die cutting precision | ±0.1 | ±0.1 | ±0.1 | ±0.1 |
Max.die-cutting speed | 4500 sheets/h | 4500 sheets/h | 4500 sheets/h | 4000 sheets/h |
Max.Feeding Pile Height | 1400mm(above thelevel) | 1400mm(above thelevel) | 1400mm(above thelevel) | 1400mm(above thelevel) |
Safe and reliable pre-stack device makes paper-pile tidier.Economic and practical manual paper feeding efficiently solves the problems, such as wrapping paper’s difficultly entering and paper’s not reaching the right position.
Automatic rising paper feeding platform makes work more convenient and quick.It is convenient to adjust the stable front lay and side lay. LCD displays the machine state, trouble reason and troubleshooting, which fully actualizes man-machine communication and makes operation more convenient.
Electric control system adopts microcomputer control, actualizing feeding, die cutting and delivery’s automatic control and timely detection. *Various safety devices actualize safe and reliable operation.
High-precision indexing mechanism is adopted to ensure accurate index and steady running. Pneumatic clutch from Italy delivers large torque. The patent card board technology of Nikko Holding of Japan combined with simple plate frame device makes installation and change of plate faster and secondary installation quicker. At the same time large plate’s dropping problem is resolved.
