Self Adjustable Roller Stand，Welding Tube Roller Stand，Welding Machine Connection-Jinan FAST CNC Machinery Co., Ltd
US$ 10000 - 15000
MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
FAST
Place of Origin:
China
Model Number:
HGZ
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
40 days
Related Products
-
Hydraulic Notching Machine For Angles，Hydraulic Angles Notching Machine，Hydraulic Angles Cutting Machine Manual RotaryUS$ 10000 - 12000MOQ: 1 Set -
Spare PartsUS$ 10 - 100MOQ: 1 Set
-
Hydraulic Linking And Straightening Machine For Formed Steel Pipe Model HX1500 And CS Conveyor Chain MachineUS$ 10000 - 20000MOQ: 1 Set
-
Jinan FAST CNC Heating/Cold Bending Machine For Angles &Plates in Telecommunication IndustryUS$ 10000 - 20000MOQ: 1 Set
-
Jinan FAST CNC Supply Beveling/Chamfering Machine Model JD20 For Metal Material ChinaUS$ 10000 - 20000MOQ: 1 Set
Brand Name
FAST
Place of Origin
China
Model Number
HGZ
Self Adjustable Roller Stand
APPLICATION
The machine is used for welding tubes. This machine can be adjusted according to the size of the tubes. It adopts stepless speed adjustable.It is with advanced product performance and reliable quality. It offers a variety of specifications for the choice. It can be designed and manufactured according to client's special requirements.
TECHNICAL DATA
| Model | HGZ25 | HGZ10 | HGZ20 | HGZ30 | HGZ50 | HGZ70 | HGZ100 |
| Loading Weight (Ton) | 5 | 10 | 20 | 30 | 50 | 70 | 100 |
| Center Distance (mm) | 700 | 960 | 1200 | 170 | 2100 | 2200 | 2300 |
| Diameter of the Roller (mm) | φ200 | φ250 | φ300 | φ370 | φ400 | φ450 | φ500 |
| Width of the Small Roller (mm) | 130 | 150 | 220 | 260 | 300 | 370 | 480 |
| Width of the Large Roller (mm) | 350 | 400 | 800 | 900 | 1200 | 1500 | 1800 |
| Diameter of the Workpiece (mm) | φ2000 | φ2500 | φ3500 | φ4400 | φ5000 | φ5500 | φ5500 |
| Height (mm) | 680 | 750 | 1000 | 1050 | 1220 | 1250 | 1300 |
| Max. Width (mm) | 635 | 760 | 900 | 1120 | 1160 | 1200 | 1250 |
| Length (mm) | 1330 | 1680 | 1990 | 2470 | 3015 | 4100 | 4200 |
★ All of these models can be customized according to customer requirements.
