Help CenterPs8815Intelligent Pressure Gauges
Related Products
-
PS4812/PS4812TProgrammable Intelligent Pressure IndicatorUS$ 81 - 134MOQ: 1 Piece -
PS4810/PS4810T Intelligent Pressure IndicatorUS$ 70 - 100MOQ: 1 Piece
-
PS1016 Intelligent Pressure GaugesUS$ 60 - 100MOQ: 1 Piece
-
PS1016T Intelligent Pressure /Temperature IndicatorUS$ 70 - 100MOQ: 1 Piece
-
SAND PS1016-035-205-311US$ 60 - 130MOQ: 1 Piece
Introduction
Sunon convenient automatic operation;
Never wear buttons more reliable;
Pattern observed more intuitive style lights;
More than 20,000 hours trouble-free operation;
Two voltage alarm, power protection;
The perfect combination of triple anti-jamming technology to ensure stable and reliable;
Large digital display clearer, ultra-thin body design table saves installation space;
Can provide 0 ~ 10V / 4 ~ 20mA current output signal voltage and other types (optional)
Specifications
| Model |
Pressure Range |
Power supply |
The output signal |
Alarm |
Input Signal |
Dimensions |
Temperature Configuration |
Communication |
| PS8815 96×96mm 方表 |
0~5~150Mpa 范围可选 (必选参数） |
空:85~265VAC （默认为空） 101: 24VDC 111: 110VAC 122: 220VAC 124: 240VAC （可选参数） |
200: 无输出信号 20X: 线性输出 201: 0~5V 202: 1~5V 203:0~10mA 204:0~20mA 205:4~20mA 206: 0~10V （必选参数） |
300: 无报警功能 31X:继电器报警 310:上限 311:上/下线 312:上/上上限314:下限 （必选参数) |
空：2.0mV/V (默认） 420:2.0mV/V （可选功能） |
|
无测温 | 无通讯 |
| PS8815 48×96mm 方表 |
|
Order Format
Format: PS8815--Rang Code--Power Code--Output Code--Alarm Code--Input Code--Shape Code
e.g:PS8815-025-200-311
Product Model"PS8815",Intelligent pressure indicator.
Pressure Rang Code"025",The pressure rang is 0~25MPa;
Output Signal Code"200",No signal output;
Alarm Methods Code"312",Adopts 2-way relay top and top's top limitation alarm;
Vacancies and not marked function codes are the default values.
