Help CenterPCD Medium Grinding,vitrified Diamond Pcd Grinder Wheel
Related Products
-
Resin Bond Diamond Grinding Wheel for Carbide 1A2 1A1US$ 0.1 - 0.5MOQ: 1 Piece -
Superabrasive Diamond & Cbn Grinding Wheels,1A1 Diamond Grinding Wheel, Flat Diamond Wheel For Carbide GrindingUS$ 0.1 - 0.5MOQ: 1 Piece
-
3A1 Diamond Wheel For Grinding PCB Micro DrillUS$ 0.1 - 0.5MOQ: 1 Piece
-
14A1 Diamond Wheel For Grinding Carbide Rod,Flat Diamond Wheel For Carbide GrindingUS$ 0.1 - 0.5MOQ: 1 Piece
-
Diamond Drill Grinding Wheel,grinding Machine Micro Drills,Diamond/ CBN Wheels for Grinding PCB Micro Drill and Milling CutterUS$ 0.1 - 0.5MOQ: 1 Piece
Especially for super finish grinding of PCD/PCBN tools
Fast Grinding
Good self-sharpening and rigidity
Superior insert edge quality
Good tool shape retention
Long tool lifespan
PRODUCT DETAILS
Application:
Especially for super finish grinding of PCD/PCBN tools. Usually for finish grinding, grits choose 3000# and 4000#, some even use 6000#.
Advantages:
1. Fast Grinding
2. Good self-sharpening and rigidity
3. Superior insert edge quality
4. Good tool shape retention
5. Long tool lifespan
DRAWING&SPECIFICATION
Type |
D(mm) |
T(mm) |
H(mm) |
W(mm) |
X(mm) |
|
6A2 |
100 |
40 |
32,40 |
3,5,10,20 |
10 |
125 |
40 |
32,40 |
3,5,10 |
10 |
|
150 |
40 |
32,40 |
3,5,10,15,20 |
10 |
|
Grit: 325/400, W40(500#), W28(600#), W20(800#), W10(1500#), W7(2000),W5(3000#), W3.5(4000#),6000#... | |||||
Suitable Grinding Machines:COBORN,EWAG, FARMAN,MYTECH...
Grain Size Selection:
Grain Size |
Machining Type |
Application |
W40(400-500#,D35)W28(600-700#,D20) |
rough |
Regrinding a blade edge profile and sharpening of much worn inserts |
W20(800-1000#,D20) |
universal |
Standard grain size also can get a high sharpening efficiency, good quality surfaces |
|
W10 (1500#, D15A) W7(2000#,D15B) |
finish |
Finishing grinding - getting a very good quality of machined surfaces |
|
W5 (3000#, D7) W3.5 (4000#,D3) |
super finish |
Super finish grinding - getting a brilliant quality of machined surfaces |
