Help CenterTPX6111 TPX6111B TPX6111C TPX6113 Engine Horizontal Heavy Boring and Milling Machine for Metal Head
Related Products
-
TPX6111B TPX6111 TPX6113 Vertical Milling and Boring Machine for MetalUS$ 35,000 - 56,000MOQ: 1 Set -
TPX6111 Vertical CNC Boring and Milling MachineUS$ 5,000 - 6,000MOQ: 1 Set
-
BO130 Horizontal CNC Boring Machine for MetalUS$ 5,000 - 6,000MOQ: 1 Set
-
Tpx6111b TPX6111 TPX6113 Cnc Horizontal Milling and Boring MachineUS$ 55,000 - 86,000MOQ: 1 Set
-
Small Machinery TPX6113 Horizontal Boring and Milling Machine for SaleUS$ 35,000 - 56,000MOQ: 1 Set
TPX6111C vertical boring and milling machine for metal
Details:
· rigid, hardened and precision-ground square guides ensure many years of accurate operation
· mechanical functions that may not be run simultaneously are provided with interlocks
· headstock and feed gears are equipped with an overload clutch
· lever-operated shift gears for positioning of the wheels in the desired position
· Faceplate and drill spindle with different task-specific speed ranges according to the various functions
· table rotates 360
· telescoping steel cover protects the guides from chips and dirt
· BO 110 incl. tailstock
3-axis position indicator
· more accuracy
· lower error rate
· increased productivity
· resulting in valuable time savings
· for increased productivity
· easy to read display
· operator-specific features
· convenient keyboard layout
· resolution: 0.01/ 0.005 mm
· default coordinates
· axis position is maintained when display is turned off
· hole circle pattern calculation
· calculator function
· storage for 10 tools
· radius / diameter toggle
· mm/inch conversion
· easy expansion and maintenance-free operation
Technical Data:
Item |
Unit |
TPX6111B |
TPX6111B/2 |
TPX6111B/3 |
|
spindle |
Boring spindle diameter |
mm |
110 |
110 |
110 |
Spindle taper |
- |
Morse No 6(ISO7:24 50#) |
Morse No 6(ISO7:24 50#) |
Morse No 6(ISO7:24 50#) |
|
Max. spindle torque |
N.m |
1225 |
1225 |
1225 |
|
Max. spindle thrust |
N |
12250 |
12250 |
12250 |
|
Number of spindle speed |
- |
22 |
22 |
22 |
|
Range of spindle speed |
r/min |
8-1000 |
8-1000 |
8-1000 |
|
Power of main motor |
kW |
7.5 |
7.5 |
7.5 |
|
Facing head |
Max. facing head torque |
N.m |
1960 |
1960 |
1960 |
Facing head diameter |
mm |
600 |
600 |
600 |
|
Range of facing head speed |
r/min |
4-200 |
4-200 |
4-200 |
|
Number of facing head speed |
- |
18 |
18 |
18 |
|
Table working |
Table working surface(L*W) |
mm |
1100*960 |
1100*960 |
1250*1100 |
Max. permissible load on table |
kg |
2500 |
2500 |
3000 |
|
T-slot size |
mm |
22*7 |
22*7 |
22*7 |
|
Feed |
Rapid speed |
mm/min |
2500 |
2500 |
2500 |
Range of spindle, headstock and table feeds per speed |
mm/rev |
0.04-6 /0.01-1.88 |
0.04-6 /0.01-1.88 |
0.04-6 /0.01-1.88 |
|
Accuracy |
Positioning accuracy |
mm |
0.005 |
0.005 |
0.005 |
Positioning accuracy |
mm |
0.001 |
0.001 |
0.001 |
|
Overall dimensions (L*W*H) |
mm |
4910*2454*2750 |
4910*2870*2750 |
5120*3380*3100 |
|
Net weight |
kg |
13000 |
14500 |
18000 |
|
