BO130 Horizontal CNC boring machine for metal
- 10 Set / Sets per Month
- Qingdao
- T/T Credit Card
- Z30100 High strength radial drilling machine FOR METAL LARGE DRILLING
- High strength radial drilling machine Z3063 FOR METAL DRILLING
- Small bench Metal Vertical Pedestal mini Drilling Machine and tapping milling Z5035 Z5040 Z5050 Bore Hole Core machinery price
- Supply Z5032-5050 metal drilling machine
- Supply ZQ3050 50mm gear Radial Drilling Machine price
- LT-160J Pedestal drill machine
Product Details
Brand Name: | Steel Horse | Place of Origin: | Shandong, China | Model Number: | BO130 |
After-sales Service Provided: | Engineers available to service machinery overseas | Condition: | New |
Product Description
The largest factory in China,BO130 Horizontal type CNC boring machine for metal
Details:
· 4-sided machining
· rigid square guides ensure consistent work accuracy
· Hauptspindelantrieb mit AC-Servomotor for hohe Leistung und Drehmoment
· wide machine bed with 4 guideways
· rigid milling table with high load capacity for part weights up to 5 tons
· economic and intuitive 3-axis CNC control
· high-quality, high-precision preloaded ball screws supported by special bearings ensure maximum positioning accuracy for all feed axes
· telescoping stainless steel covers protect the guides from chips and dirt
· rotary table with manual clamping can be locked at 4 positions: 0, 90, 180 and 270
Technical Data:
Drilling capacity Counter-boring capacity Table dimensions Table load capacity Number of T-slots T-slots, width T-slots, spacing Spindle center-to-table distance
|
50 mm 250 mm 1.000x1.350 mm 5.000 kg 7 Pieces 22 mm 125 mm 0 - 1.140 mm
|
Travels Travel X-axis Travel Y-axis Travel Z-axis Travel W-axis
|
1.500 mm 1.140 mm 1.000 mm 550 mm
|
Headstock Spindle speed Spindle diameter Headstock torque Spindle mount
|
12 - 1.000 rpm 130 mm 1.330 Nm BT 50
|
Feed Max. torque feed motor (X,Z) Max. torque feed motor (Y,W) Feed speed X-axis Feed speed Y-axis Feed speed Z-axis Feed speed W-axis
|
22 Nm 30 Nm 5 - 2.000 mm/min 5 - 2.000 mm/min 5 - 2.000 mm/min 5 - 2.000 mm/min
|
Accuracies Positioning accuracy X-axis Positioning accuracy Y-axis Positioning accuracy W-axis Positioning accuracy Z-axis Repeatability X-axis Repeatability Y-axis Repeatability Z-axis Repeatability W-axis Work table rotation accuracy Work table repeatability
|
0,04 mm 0,04 mm 0,03 mm 0,03 mm 0,02 mm 0,02 mm 0,015 mm 0,015 mm ± 10" (4x90°) ± 5" (4x90°)
|
Rapid feed Rapid feed X-axis Rapid feed Y-axis Rapid feed Z-axis Rapid feed W-axis
|
10.000 mm/min 10.000 mm/min 5.000 mm/min 10.000 mm/min
|
Drive capacity Motor rating main drive Main drive, continuous load
|
22 kW 18,5 kW
|
Measures and weights Overall dimensions (length x width x height) Weight
|
5,01x3,7x3,6 m 17.000 kg |
Steel horse CNC milling machine product list | |||||
series | Model | Table size(mm) | Table travel(mm) | Weight(kg) | |
Mini series (for small milling work,school teachj,machine price is cheap,function | DB30CNC | 450*160 | 300*150*290 | 350 | |
XHK7120 | 600*200 | 350*220*400 | 585 | ||
XK7125 | 1000*250 | 535*320*375 | 1700 | ||
M400 BT30 BT40 | 1000*240(320) | 550*330*450 | 1400 | ||
Light type series(for all of work,cheap price,every client frist choice,can do any work)
| VMC320(VMC7032) | 1000(800)*320 | 610*320*400 | 2350 | |
VMC350(VMC7035) | 950*350 | 650*350*500 | 2600 | ||
VMC400(VMC7040) | 900*400 | 700*400*550 | 2700 | ||
Heavy type series(for heavy,big work)
| VT320L | 800*320 | 500*320*420 | 2700 | |
VT500L | 950*500 | 800*500*550 | 5500 | ||
VT600L | 1300*600 | 1000*600*650 | 8000 |
