LT Vertical Cylinder Boring Machine

Name: LT Vertical Cylinder Boring Machine
Brand: LT EQUIPMENT
SKU: 105879115
Availability: InStock

US$ 10,650 - 10,800 MOQ: 1 Set

Key Specifications

Condition:

New

CNC or Not:

Normal

Production Capacity:

15-20 Sets/month

L&T Mechanical & Electrical Equipment Co., Ltd.

5Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

China Port

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Production Capacity 15-20 Sets/month

Place of Origin China

Brand Name LT EQUIPMENT

Model Number LT7220B

Voltage 380V/50Hz/3Ph

Power(W) -

Dimension(L*W*H) 2250*1588*2335mm

Weight N.W./G.W.: 3800KGS/4200KGS

Certification ISO9001:2008

After-sales Service Provided Engineers available to service machinery overseas

Application

This Vertical Fine Boring Machine is mainly used to bore holes of cylinder body, engine sleeve and other parts. This machine is of high accuracy.

Fearures

1. Equipped with fast moving device in longitudinal and latitudinal ways.

2. Equipped with measuring device.

3. Digital readout decive is optional accessory

Specification

Spindle Speed Range	53-840rev/min
Spindle Feed Range	0.05-0.20mm/rev
Distance from Spindle Axis to Carriage Vertical Plane	315mm
Max Boring Diameter	φ200mm
Max. Boring Depth	500mm
Table Longitudinal Travel	900mm
Table Latitudinal Travel	100mm
Dimensions Accuracy	IT7
Surface Roughness	Ra0.8-1.6
Roundness	0.005
Cylindricity	0.02/300
Overall Dimensions(LWH)	225015882335mm
Package Dimensions(LWH)	183018002620mm
N.W/G.W	3300/3800kg
