SOLVENT BASED SCREEN INK FOR HEAT TRANSFER

1. Substrates:

Waterproof nylon fabric、non-waterproof fabric、luggage fabric、 Oxford fabric

and nylon plastic.

2. Product features:

High-gloss、good softness、strong coverage、good adhesion on high waterproof

nylon fabric.

3. Test items&results:

Adhesion: good Scratch resistance: 4-5

Wear resistance: 4-5 Crumpling resistance: 5

Acid resistance: 4-5 Alkali resistance: 4-5

Wash resistance: 3-4 Migration resistance: 4-5

4. Technical parameters:

Color shade: refer to color card Color concentration:8-15%

Fineness:≤7um Viscosity: 200-280p

Gloss: 75-85 Liquidity: 10-15mm/s

Solid content: ≥45%

5. Instructions:

(1) Mesh: 150-350 polyester mesh

(2) Squeegee: Polyurethane squeegee at the hardness 65-85 is recomm

ended. (3) Indicative dosage: 30 ㎡/㎏ on the 200 mesh

(4) Drying: natural drying (surface drying in 7-15 mins, full drying in more than

24 hours) or blow drying at temperature below 100℃.

(5) Selective Solvents: quick drying water 719, medium drying water 718

or cyclohexanone based on printing conditions.

(6) Stencil cleaning: organic solvent (e.g. stencil cleaning water)

6. Notes:

(1) Please pay attention to the solvent′s dissolving capacity while diluting the

ink.

(2) It will cause pattern scratch by the stack of finished press works on PVC

film due to the PVC′s poor solvent resistance. So pay attention to the drying

status of ink when finish work and avoid excessive overlap.

(3) Color migration will occur while printing on PVC film containing a lot of

plasticizers. The printing ink with good anti-permeability is recommended.

(4) The rigorous sample test before use is necessary to check the printing

ink′s adhesion on different waterproof nylon fabrics.

(5) The catalyst 9004 should be added appropriately (by 5-8%) into the ink to

improve adhesion when printing on waterproof nylon fabric. But the printing ink

with added catalyst must be finished within 8 hours, or will be scrapped.

7. Storage:

It can be stored for 36 months at 5-35℃. Keep away from strong light. Avoid

strong acid and strong alkali.

8. Remarks:

(1) Please thoroughly read the instructions and make a sample test before

use.

(2) The technical data is for reference only.
