Wellhead Swivel Joint 1" Fig 1502 x 15000psi Working Pressure
Wellhead Fitting 1" x Fig 1502 Swivel Joint
General of the 1" Fig 1502 Swivel Joint
JC Wellhead is specilized in designed and manufactured various models of swivel joints and their repair kits. The 1" Fig 1502 Swivel Joint is suitable for normal or low temperature and H2S environments. The sizes of swivel joint is ranging from 1" to 4" and related Working Pressure ranging from 2000psi to 20000psi.
There are long and short radius swivel joints available. Long radius swivel joints can minimize fluid shock, and has better performance of resistance for scouring an corrosion. We also need to use short radius swivel joint for low pressure operation due to limited installation space.
Specification of the Swivel Joint
Nominal Diameter(in) | Connection Type | Pressure (psi) | Standard Length (mm) A | Standard Length (mm) B | Standard Length (mm) C |
1" | Inner Thread | 10000 | 181 | 189 | 181 |
1" | 1502(M*F) | 15000 | 213 | 188 | 213 |
1" | 1502(M*F) | 15000 | 213 | 188 | 213 |
1.5" | Inner Thread | 10000 | 202 | 238 | 202 |
1.5" | 1502(M*F) | 15000 | 257 | 238 | 257 |
1.5" | 1502(M*F) | 15000 | 257 | 238 | 257 |
2" | Inner Thread | 10000 | 229 | 272 | 229 |
2" | 1502(M*F) | 15000 | 277 | 272 | 277 |
2" | 1502(M*F) | 15000 | 277 | 272 | 277 |
2" | 1502(F*F) | 15000 | 224 | 272 | 277 |
2" | 2002(M*F) | 20000 | 277 | 275 | 315 |
2" | 2002(M*M) | 20000 | 318 | 277 | 318 |
3" | Inner Thread | 15000 | 327 | 417 | 327 |
3" | 1502(M*F) | 15000 | 368 | 417 | 366 |
3" | 1502(M*F) | 15000 | 366 | 417 | 366 |
3" | 2002(M*F) | 20000 | 518 | 538 | 518 |
4" | 1002(M*F) | 10000 | 409 | 460 | 411 |
4" | 1002(M*F) | 10000 | 404 | 460 | 411 |
4" | 1502(M*F) | 15000 | 518 | 538 | 518 |
Wellhead Swivel Joint 1" Fig 1502 x 15000psi Working Pressure
Wellhead Fitting 1" x Fig 1502 Swivel Joint
