First class quality anti-corrosion pipe based water well screen SS316L:
Pipe based well screens consist of base pipe, all-welded wedge wire screen and supporting rod. The base pipe is perforated or slotted API casing pipe. The base pipe can be stainless steel or carbon steel API 5CT casing. The all-welded wedge wire screens are welded together with base pipe by supporting rod.Having the API casing inside a wire wrap screen jacket is supporting the screen and enhance the capabities and high tensile strength Loads. Pipe base can be made from API pipe Seamless casing spiral or stainless steel casing. Opening area for the base pipe is up to 15% and for the jacket is up to 30%. Jacket slot size is between 0.15mm to 3mm.
Size table of the Pipe Based Well Screens
Package of two layers water well screen
Each with bubble bags and then in wooden case.
Each case is clearly marked with:
1.Batch number
2.Date of manufacture
3.Safe heating & application temperature
b. Delivered punctually, no delay.
c. Delivery modes: by sea, air, railway and express.
Our Service
Pipe Based Well Screens for wholesale
Prompt,professional and patient reply;
Offer best quality products;
Recommend the most suitable products.
2.After-sales Service
Timely tracking cargo transportation;
Building customer files for regularly visit;
Free replacement of damaged products;
Deal with customers`dissatisfaction and complaints;
Send gift to our customers.
3.Customized packing is always welcomed.
4.Assist to arrange transportation
