Home > Metallurgy, Mineral & Energy > Magnetic Material > NdFeB Magnet > Rcyd Self-Cleaning Permanent Magnetic Separator for Cement, Chemical, Ceramic
Rcyd Self-Cleaning Permanent Magnetic Separator for Cement, Chemical, Ceramic
US$ 500 - 3000
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Zhitian
Place of Origin:
China
Model Number:
RCYD
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao/Tianjin/Shanghai
Delivery Detail:
45 days
Related Products
-
Rcdd Self-Cleaning Electromagnetic SeparatorUS$ 500 - 3000MOQ: 1 Piece -
Rcde Oil-Cooling Electromagnetic Separator for Belt ConveyorUS$ 500 - 3000MOQ: 1 Piece
-
Rcyb Series Suspension Permanent Magnetic SeparatorUS$ 500 - 3000MOQ: 1 Piece
-
Rcdb Dry Electromagnetic Separator for Removing Iron in Cement/Power/Chemical/Coal Mine/MetallurgyUS$ 500 - 3000MOQ: 1 Set
-
Gjt-F Metal DetectorUS$ 1800 - 3000MOQ: 1 Piece
Brand Name
Zhitian
Place of Origin
China
Model Number
RCYD
Shape
Other, rectangle
Type
Permanent
Application
Industrial Magnet
Composite
NdFeB Magnet
Features:
-- Made of NdFeB
-- Energy saving,easy to install and convenient to use
-- High efficiency and stable performance,good operational reliability and flexibility
-- It is made up of the drum-shaped roller, whole-sealed cast steel bearing pedestal, which make the separator work in the harsh environment,water-proof, dust-proof and corrosion resisting.
-- reliable function, unique magnetic circuit, strong magnetic force, and high magnetic gradient.
| NO. | Model | Adaptive belt width (mm) |
Suspension height (h=mm) |
Material depth (≤mm) |
Magnetic intensity (≥mt) |
Belt speed (m/s) |
Working system |
Existing power (≤kw) |
Weight (kg) |
Appearance size (mm) |
||||
| A | B | C | D | E | ||||||||||
| 1 | RCYD-5 | 500 | 150 | 100 | 60 | 4.5 | Continuous | 1.5 | 750 | 1900 | 735 | 935 | 950 | 753 |
| 2 | RCYD-6 | 600 | 180 | 130 | 60 | 1.5 | 920 | 2020 | 780 | 1030 | 1100 | 840 | ||
| 3 | RCYD-6.5 | 650 | 200 | 150 | 70 | 1.5 | 1200 | 2165 | 780 | 1080 | 1200 | 888 | ||
| 4 | RCYD-8 | 800 | 250 | 200 | 70 | 2.2 | 1400 | 2350 | 796 | 1280 | 1300 | 1088 | ||
| 5 | RCYD-10 | 1000 | 300 | 250 | 70 | 3 | 2120 | 2660 | 920 | 1550 | 1400 | 1335 | ||
| 6 | RCYD-12 | 1200 | 350 | 300 | 70 | 4 | 3350 | 2860 | 1010 | 1720 | 1550 | 1515 | ||
| 7 | RCYD-14 | 1400 | 400 | 350 | 70 | 5.5 | 4450 | 3225 | 1050 | 1980 | 1800 | 1755 | ||
| 8 | RCYD-16 | 1600 | 450 | 400 | 70 | 7.5 | 6200 | 3350 | 1180 | 2160 | 1950 | 1850 | ||
| 9 | RCYD-18 | 1800 | 500 | 450 | 80 | 7.5 | 8100 | 3580 | 1210 | 2450 | 2200 | 2130 | ||
| 10 | RCYD-20 | 2000 | 550 | 500 | 80 | 7.5 | 9700 | 3800 | 1300 | 2700 | 2400 | 2410 | ||
| Note:All themodels have T1,T2,T3design whose magnetic intensity is higher than standard. The magnetic 90mt,120mt and 150mt separately,Discard iron belt can be equipped with armor. | ||||||||||||||
