Automatic Nozzle Cleaner, Nozzle Cleaner, SMT Nozzle Cleaner,CW-36 Contrast with traditional cleaning ：
1、 Artificial wind guns
① Manual cleaning efficiency is low, the nozzle surface and the lumen can not be cleaned, the hole with a steel wire stabbed easily damaged;
② Cleaning effect difference;
③ The use of cleaning fluid and alcohol may penetrate to cause the reflective layer to fall off.
before cleaning after cleaning
2、 Ultrasonic cleaning
① Low cost and high efficiency;
② Cleaning process can easily lead to collision
between the nozzle, resulting in damage to the surface
of the black coating or fall off;
③ Cleaning fluid on the nozzle surface coating damage, greatly reducing the use of nozzle life;
④ Can not completely clean the nozzle surface and lumen;
⑤ For the latest 01005 and 0201 nozzle can not be a
good cleaning, mainly due to the nozzle hole is too small, ultrasonic cleaning can cause vacuum bubbles can not be discharged and cleaning is not clean.
4. Professional Ultrasonic Stencil Cleaning,Stencil Washing Economic Benefits:
① Reduce the purchase cost of the nozzle;
Use CW-36 washing machine can be a good solution to the nozzle dirty and scrapped, so as to extend the service life.
② Reduce unnecessary labor;
As the machine uses automatic cleaning, so no special person responsible for all the machine automatically completed the entire process.
③ Effectively reduce the product defect rate, improve SMT productivity;
A large part of the production process is due to the dirty surface of the nozzle and the cavity is too dirty caused by throwing or placement of displacement, resulting in poor order after welding. After using the washing machine can make the nozzle always protect the new state, greatly improve the production efficiency.
CW-36,Washing Machine Industrial Cleaning Machine:
1： Composition Introduction:
1.1： mechanical ：All the key parts of the whole use of imported 304 stainless steel, special parts of the use of imported 316 stainless steel to
The warranty machine will not rust due to the use of water, thus affecting the equipment life and other security risks;
1.2： pneumatic ： The use of all imports of SMC pneumatic components, to better ensure a stable and efficient work efficiency;
1.3： control ： The machine adopts high quality touch screen man - machine interface, PLC control;
2： Precautions:
2.1：Do not open the water cover in the ventilation cleaning or drying. If there is a high pressure in the storage tank,Mouth jet out.
2.2：Please use distilled water or industrial deionized water, do not use mineral water or tap water, such water contains minerals and bleach, the nozzle will cause damage and damage;
2.3： After each cleaning is completed using air guns to dry the residue in the studio;
2.4： After each time you place the nozzle, make sure that the nozzle is fully seated and the nozzle is fit with the fixture.2.5：Place the tool into the studio when the carousel should be careful not to hit the telescopic cylinder nozzle, If not very strong collision does not affect the nozzle and the concentricity of the device. Sprinkler and appliance concentricity The factory is positioned by positioning the sensor. Such as strong collision lead to concentricity are not allowed to contact with the after-sales maintenance staff in a timely manner;
2.6： Regularly replace the equipment intake filter every year, The general replacement of the filter time for a year, depending on the factory gas source clean to determine, such as filter filter yellow or black need to immediately replace.
If you need the machine,please contact us:
Skype/Email: s5@smtfly.com
WhatsApp/Wechat: +86 136 8490 4990
