Sand Blast Nozzles

Boron Carbide Venturi nozzles with aluminium jacket

Entry: 1"
Thread: 1-1/4-11-1/4 NPSM
Code Orifice mm Length mm
BCVA25/32-4.8/130 4.8 130
BCVA25/32-6.4/135 6.4 135
BCVA25/32-7.9/140 7.9 140
BCVA25/32-9.5/165 9.5 165
BCVA25/32-11.1/190 11.1 190
BCVA25/32-12.7/215 12.7 215

Entry: 1-1/4"
Thread: 2 -4-1/2 UNC
Code Orifice mm Length mm
BCVA32/50-3.25/100 3.25 100
BCVA32/50-4.0/110 4.0 110
BCVA32/50-4.8/130 4.8 130
BCVA32/50-4.8/130 4.8 130
BCVA32/50-6.4/135 6.4 135
BCVA32/50-7.9/140 7.9 140
BCVA32/50-9.5/165 9.5 165
BCVA32/50-9.5/187 9.5 187
BCVA32/50-11.1/190 11.1 190
BCVA32/50-12.7/215 12.7 215

Tungsten carbide double venturi nozzles with aluminium jacket
Entry: 1",
Thread: 1-1/4 -11-1/4  NPSM
Code Orifice mm Length mm
BCDVA25/32-4.8/140 4.8 140
BCDVA25/32-6.4/140 6.4 140
BCDVA25/32-7.9/160 7.9 160
BCDVA25/32-9.5/160 9.5 160
BCDVA25/32-11.1/185 11.1 185
BCDVA25/32-12.0/185 12.0 185
BCDVA25/32-14.0/205 14.0 205
BCDVA25/32-16.0/205 16.0 205

Entry: 1-1/4",
Thread: 2- 4-1/2UNC
Code Orifice mm Length mm
BCDVA32/50-4.5/133.4 4.5 133.4
BCDVA32/50-6.5/133.4 6.5 133.4
BCDVA32/50-8.0/139.7 8.0 139.7
BCDVA32/50-10.0/165.1 10.0 165.1

Boron carbide  venturi nozzles with stick-up aluminium jacket

For ID 25mm hose
Code Orifice mm Length mm
BCVA25S-8/100 8.0 100
BCVA25S-10/100 10 100


Boron carbide straight nozzles
Code OD mm ID mm Length mm
BCS15 15 5 45
BCS21 OD 21 id 3,4,5,6,7,8,9,10, L 33, 35 ,40 ,45 ,50 ,60 ,75 ,80 ,90 ,100
BCS25 25 12 85
Aluminium jacket with threds available upon require.


Tungsten carbide venturi nozzles with aluminium jacket

Entry: 1"
Thread: 1-1/4 -11-1/4 NPSM
Code Orifice mm Length mm
TCVA25/32-6.4/140 6.4 140
TCVA25/32-8.0/145 8.0 145
TCVA25/32-9.5/165 9.5 165
TCVA25/32-11.0/200 11.0 200
TCVA25/32-12.7/225 12.7 225

Entry: 1-1/4"
Thread: 2 - 4-1/2 NPSM
Code Orifice mm Length mm
TCVA32/50-6.4/130 6.4 130
TCVA32/50-8.0/145 8.0 145
TCVA32/50-9.5/165 9.5 165
TCVA32/50-11.0/200 11.0 200
TCVA32/50-12.7/210 12.7 210
TCVA32/50-12.7/225 12.7 225
TCVA32/50-14.0/225 14.0 225
TCVA32/50-16.0/225 16.0 225
TCVA32/50-19.0/225 19.0 225

Tungsten carbide short venturi nozzles with aluminium jacket
Entry: 1-1/4"
Thread: 2 -4-1/2 UNC
Code Orifice mm Length mm
TCVA32/50-6.4/85 6.4 85
TCVA32/50-8.0/85 8.0 85
TCVA32/50-9.5/85 9.5 85
TCVA32/50-12.7/85 12.7 85


Tungsten carbide double venturi nozzles with aluminium jacket
Entry: 1", Thread: 1-1/4-1-1/4 NPSM
Code Orifice mm Length mm
TCDVA25/32-6.5/145 6.5 145
TCDVA25/32-8.0/175 8.0 175
TCDVA25/32-9.0/178 9.0 178
TCDVA25/32-10/178 10.0 178
TCDVA25/32-11/195 11.0 195
TCDVA25/32-12/195 12.0 195

Tungsten carbide  venturi nozzles with stick-up aluminium jacket
For ID 32mm hose
Code Orifice mm Length mm
TCVA32S-7.9/100 7.9 100
TCVA32S-9.5/100 9.5 100
TCVA32S-11.5/100 11.5 100
TCVA32S-12.7/100 12.7 100

For ID 32mm hose
Code Orifice mm Length mm
TCVA32S-8/120.7 8.0 120.7
TCVA32S-9.5/20.7 9.5 120.7
TCVA32S-11/120.7 11.0 120.7
TCVA32S-12.7/120.7 12.7 120.7


Tungsten carbide straight nozzles
Code OD mm ID mm Length mm
TCS16 16 7 35
TCS20 OD 20, id 6, 8, 12, L 35 ,45 ,60
Aluminium jacket with threds available upon require
