ESD-2000/2005 Electrostatic Discharge Generator
1. Introduction
ESD-2000/2005 ESD generator is completely meet the requirements of IEC61000-4-2. The max output voltage can reach 20KV (ESD-2000)/3KV(ESD-2005), and has the features of compact structure, multiple functions and easy operation, can applied to most electronic equipment for ESD testing, like mobile, PC, MP4, digital TV, power adaptor, Li-battery, electric toy, LED lighting, vehicle electronic, treadmill and etc.
2. Specification
ModelESD-2005ESD-2000
Output voltage0.5～30kV±3％0.1～20kV±3％
PolarityPositive, negative
Trigging modeSINGLE, COUNT, 20PPS, *
Discharge modeAir discharge, contact discharge
Discharge interval0.1～9.9s (0.05S @ 20pps mode)
Numbers of discharge0～999
Energy storage capacitance150pF±10％
Discharge resistor:330Ω±10％
discharge electrodeConical contact discharge electrode and spherical air discharge electrode
Air discharge voltage keep time More than 5S
Working environmentAmbient temperature:10℃～35℃ humidity:30％～60％
PowerSingle AC85～265V，50／60Hz
Dimension and weight250×210×130mm（D×W×H）/4kg
