Camera Link™ Shrunk Delta Ribbon (SDR) Cable Assemblies AIA Mini Camera Link Full
Product Description:
High Speed Mini Camera Link cable SDR/HDR 26Pin
Here the High Speed Mini Camera Link cable SDR/HDR 26Pin CameraLink cable is fully compatiable with Camera Link™ Shrunk Delta Ribbon (SDR) interface.
|
he Mini Camera Link™ (SDR) Cable Assembly solution is constructed of a rugged, over-mold shell with a reliable thumbscrew locking system. The assemblies have been developed to address the multitude of options now available with the introduction of Mini Camera Link® (mini CL). Features:
1: an over-mold, right angle configuration that provides a low profile, thumbscrew interface. The right angle option reduces the assembly profile by over four inches when compared to traditional straight exit backshell options. 2: the extender assembly with female SDR / MDR connector that can be coupled with SDR / MDR connector,this is used for adding length to the existing cables or providing a means for transition through a bulkhead/mid-span requirement. The extender cables feature over-mold MDR receptacles. Compatiable Part Number: 1MF26-L560-00C-500 1MF26-L560-00C-200 1SF26-L120-00C-200 1SF26-L12000C100 1MG26-LFW000C100 1MF26-L560-00C-A00 1MF26-L56000C100 1MG26-LFW000C500 1SF26-L120-00C-500 1MG26-LFW0-00C-200 1SF26-L12000CA00 1MF26-L576-00C-200 1SF26-L13700C100 1SF26-L13700C500 1SF26-L13600C100 1MF26-L576-00C-500 1SF26-L136-00C-200 1MG26-LFW000CA00 1SF26-L13700CA00 1SF26-L13700C200 1SF26-L13600C500 1MF26-L58700C100 1MF26-L58700C500 1MF26-L58600C200 1MF26-L58700CA00 1MF26-L577-00C-A00 1MF26-L58600C100 1MF26-L58700C200 1MF26-L576-00C-A00 |
Price difference according to quantities, please enquire Tel: +86-755-29703902 mobile: +86-13760160092
We can design and do customized cables, Sample can be offered for evaluation.
Camera Link cable connector connection type including:
MDR Male Straight Exit, MDR Female Straight Exit, MDR Male Low Profile R/A Exit UP, MDR Male Low Profile R/A Exit DWN,
HDR / SDR Male Straight Exit, HDR / SDR Male R/A Exit UP w/Recessed Screws, HDR / SDR Male R/A Exit DOWN
W/Recessed Screws, MDR Male Ext. Profile R/A Exit UP, MDR Male Ext. Profile R/A Exit DWN, MDR Male Exit RIGHT w/Recessed Screws
MDR Male Exit LEFT w/Recessed Screws, HDR / SDR Female Straight Exit,
14P HDR / SDR PoCL Lite Straight Exit w/Recessed Screws, MDR Latch Type Straight Exit, HDR / SDR Male Exit RIGHT w/Recessed Screws, HDR / SDR Male Exit LEFT w/Recessed Screws,
HDR / SDR Male R/A UPExt. Profile w/Recessed Screws, HDR / SDR Male R/A DWN Ext. Profile w/Recessed Screws.
CameraLink cable China supplier
