Automatic Industrial Coal Analyzer
- 500 Set / Sets per Month
- Shanghai
- T/T
- Winner3005 dry particle micron measuring instruments for abrasive powder test
- Winner2000ZD laser size analysis equipment-winner
- Winner2000ZD particle measurement & analysis instruments
- Winner2000ZD particle fully automatic analyzer
- Winner312 Spray Laser Particle Size instrument
- Winner312 Spray Laser Particle Analysis Instrument
Product Details
Place of Origin: | Jiangxi, China | Brand Name: | GUANGMING | Model Number: | GMG 5000 |
Product Description
Specifications
The analyzer can automatically test moisture, volatile component and ash content of 19 coal samples at the same timeAutomatic Industrial Coal Analyzer
Features:
1. Using original imported key parts to improve the reliability of the instrument, the heating furnace adopts light-weight insulation material to make instrument lighter.
2. Adopting unique control mechanism to achieve automatic open and close of top cover to avoid heat radiation on operator.
3. In order to achieve automatically repeated weighing at a high temperature, the analyzer integrated an imported high-precision electronic balance and an automatic weighing device.
4. The instrument can test moisture, volatile component and ash content of 19 samples within 150 minutes; it is suitable for analysis of bulk coal samples.
5. The procedures of moisture and ash content are in accordance with international standard, which can be used for analysis of arbitration, also can make quick test, the volatile content error: ≤ ± 1 .
6. Adopting thermogravimetric analysis, automatic weighing and feeding sample, automatic data processing, report printing, saving and so on, the fixed carbon content, hydrogen value and calorific value will be automatically calculated by measuring the moisture, volatile and ash content.
Technical parameter:
GMG5000 Automatic Industrial Coal Analyzer | |
Weight of sample | 0.8-1.2g |
Highest working temperature | 1000Centigrade |
Precision of temperature controlling | ±3Centigrade,special: ±1Centigrade |
Quantity of samples | 1-19 pc(s) |
Precision | In accordance with GB/T212-2001 |
Accuracy | Within tolerance of the standard sample |
Testing time | Moisture and Ash content(quick way)≤120mins; International way≤180mins; Volatile component:8mins/sample |
Testing temperature | 110Centigrade(Moisture), 815Centigrade(Ash content), 900Centigrade (Volatile component) |
Power | ≤7kw |
Power supply | (220±22)VAC (50±1)HZ |
