CTM-B Series Automatic Compression Testing Machine
GB/T50081-2002,GB/T2542-2012
Characteristic:
1, The test machine adopts a frame type structure, and has a screw lifting structure, oil cylinder underneath, the lifting motor can drive the screw to adjust the test space.
2. The loading system using the latest technology of servo pump control system, ensure low noise, fast response, high stability.
3. Screw down automatically when the trial began, screw up automatically at the end of the test, which greatly saves time trials aid, ensure efficient trials.
4.10-inch touch panel PC as a man-machine interface, combined with the independent development of embedded control software, with a compact structure, convenient operation.
5. During the experiment of microcomputer can automatically display the load, strength, speed and loading curve, automatically determine the specimen broken and calculate and save the test results, can query and print the complete test report.
| Model | CTM-2000 | CTM-3000 |
| Max.Load Capacity (KN) | 2000 | 3000 |
| Measuring Range (KN) | 200-2000 | 300-3000 |
| Indication accuracy | ≤±1% | |
| Upper pressure platen size (mm) | 250×220 | 330×320 |
| Lower pressure platen size (mm) | 250×220 | 330×320 |
Max.distance between upper and lower pressure platen (mm) | 370 | |
| Max.Piston travel (mm) | 60 | 80 |
| Effective column spacing (mm) | 390 | 490 |
| Power (KW) | 1.8 | |
| Input voltage | AC220V ±10% | |
| Overall dimensions (main machine) (mm) | 980 × 440 ×1350 | 1180 × 480 × 1500 |
| Weight approx (kg) | about 1350 | about 2200 |
