UTM-S Series Universal Tensile Testing Machine /tension Machine
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
Geotest Equipments
Model Number:
UTM-100W
Payment & Shipping
Payment Methods:
Port of Shipment:
Ningbo Shanghai Negotiable
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
UTM-100Tdigital Electronic Universal (Tensile) Testing MachineNegotiableMOQ: 1 Set -
UTM-100W Universal Testing Machine New DesignNegotiableMOQ: 1 Set
-
CTM-3000 Concrete Compressive Strength Testing MachineNegotiableMOQ: 1 Set
-
CTM-3000B Automatic Compression Testing Machine/ Digital Compression Testing MachineNegotiableMOQ: 1 Set
-
UTM-1000E Hydrostatic Universal Tensile StrengthTesting MachineNegotiableMOQ: 1 Set
Place of Origin
Zhejiang, China
Brand Name
Geotest Equipments
Model Number
UTM-100W
Power
Electronic
Usage
Universal Testing Machine
UTM-S series Universal Tensile Testing Machine
ASTM E4 E74 E83 E1012 E1856
Function:
This machine is capable of carrying out tensile and compression tests, bend tests, and tests on springs. Test materials include: metals, plastics, paper, ropes, chains, and other materials.
Main technical parameters
Model |
UTM-2S |
UTM-3S |
UTM-5S |
Capacity |
2KN |
3KN |
5KN |
Grade / Class |
Class 0.5 (Class 1) |
||
Loading measuring range |
0.4% ~ 100% FS (1% ~ 100% FS) |
||
Loading accuracy |
±0.5% (±1%) |
||
Loading force resolution |
1/±300,000 F.S (same resolution in full range) |
||
Displacement resolution |
0.001mm (0.01mm) |
||
Force speed control range |
0.005% ~ 5% FS/S |
||
Force speed control accuracy |
Speed < 0.05% FS: ±1% |
||
Speed ≥ 0.05% FS: ±0.5% | |||
Deformation speed control range |
0.005% ~ 5% FS/s |
||
Deformation speed control accuracy |
Speed < 0.05% FS: ±1% |
||
Speed ≥ 0.05% FS: ±0.5% | |||
Displacement speed control range |
0.005 ~ 500 mm/min |
||
Displacement speed control accuracy |
≤±2% of set value |
||
Control range of constant-force, constant–deformation, constant-displacement |
0.5% ~ 100%FS |
||
Control accuracy of constant-force, constant-deformation, constant-displacement |
Set value ≥10%FS: ±0.5% |
||
Set value < 10%FS: ±1% | |||
Testing space (height) |
1000mm |
||
Testing space (width) |
75mm |
||
Working voltage |
220V±10%, 50Hz (good earth-connection) |
||
Motor power |
400W |
||
Dimensions |
410×430×1550 |
||
Net weight |
100kg
|
||
