UTM-50T Digital Electronic Universal Tensile Testing Machine
1. Application
a. The machine is suitable for manufacturing industry of metal, cementing compound, pipes, tubular products, proximate matter, aerospace industry, petrochemical engineering, waterproof materials, wire and cable, textile, fiber, rubber, ceramics, food, medical packaging, geotextile, thin film, wood, paper and so on.
b. It is also suitable for quality supervision departments and colleges education.
c. The machine is mainly used to do test on metal, non-metal and composite materials to determine mechanical performance index such as tensile, compression, bending and others.
d. The machine determines the max. bearing tensile force, tensile strength, elongation deformation and elongation index and other technical indexes.
e. The test date can be saved for checking and displaying, the test data can be printed out through connecting with a printer through output interface.
Our products are 100% supplied from the factory
If you are interested in our products, you can contact us directly or welcome to visit our site:
SKYPE ID: sun.nancy3
| Model | UTM-1/2/5/10T | UTM-20T | UTM-30T/50T | UTM-100T | ||
| Max. load | 1/2/5/10KN | 20KN | 30/50KN | 100KN | ||
| Class | Class 1 | |||||
| Loading measuring range | 1%-100% F.S | |||||
| Deformation min. reading value | 0.01mm | |||||
| Loading measuring accuracy | ±1% | |||||
| Displacement speed control range | 0.2-500mm/min | |||||
| Effective test span | 400mm | |||||
| Effective tensile test space | 800mm | |||||
| Effective compression test space | 700mm | |||||
| Crosshead travel | 950mm | 1000mm | 950mm | 1000mm | ||
| Distance between columns | 400mm | 400/500mm | 500mm | |||
| Loading method | Electronic | |||||
| Control method | Micro-computer controller automatically control | |||||
| Working voltage | 220V±10%, 50Hz (good earth-connection) | |||||
| Motor power | 400W | 750W | 1500W | |||
| Overall dimensions | 670x420x1600mm | 750x420x1720mm | 760x700x1760mm | 860x700x1950mm | ||
| Weight approx | 300kg | 400kg | 500kg | 600kg | ||
