Home > Industrial Equipment & Components > Boiler & Furnace > Furnace > Mesh Belt Sinter Furnace

Mesh Belt Sinter Furnace

Name: Mesh Belt Sinter Furnace
Brand: ACME
SKU: 142618526
Availability: InStock

Advanced Corporation For Materials And Equipments(ACME)

US$ 400000 - 2000000 MOQ: 1 Set

Key Specifications

Get Latest Price

Brand Name:

ACME

Place of Origin:

China

After-sales Service Provided:

Engineers available to service machinery overseas

Contact Supplier Request Quote Chat Now

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port in china

Delivery Detail:

180 days

Product Details
Company Profile
Contact Us

Brand Name ACME

Place of Origin China

After-sales Service Provided Engineers available to service machinery overseas

Condition New

Description
Mesh belt sinter furnace is mainly used for high temperature sinter of powder metallurgy ferrous and copper parts, such as oil bearing, gear, clutch plate, bushing, sleeve, etc.

Technical Features
1. The furnace is configured with RBO rapid binder removal system as required.
2. Module type heating element is used , which is convenient for maintenance and replacement without stop the furnace.
2. All fiber refractory structure guarantees faster heating rate and less energy consumption.
3. Mesh belt sintering furnace uses hanging roof structure, which is convenient for maintenance and replacement of muffle.
4. Fast cooling system is available that is mainly for hardening the ferrous material.
5. It has functions of remote control operation, remote malfunction diagnosis and remote program update functions.

Optional Configuration of Mesh Belt Sinter Furnace
1. Refractory material: silicate aluminum fiber/ceramic fiber felt
2. Heater material: 0Cr21Al6Nb, 0Cr27Al7Mo2
3. Muffle material: SiC+SiN/heat resistant steel
4. Mesh belt material: SUS310S, SUS314, SUS304
5. Process gas control: Volume/mass flow-meter, manual value/auto value, Foreign brand/Chinese brand
6. Operation panel: simulation screen/touch screen/industrial computer
7. PLC: OMRON/Siemens
8. Temperature controller: SHIMADEN/EUROTHERM
9. Thermocouple: C type/K type/N type (tungsten sheath/Moly sheath/ceramic sheath)
10. Recorder: Paperless recorder/paper recorder, Foreign brand/Chinese brand
11. Electric components: CHINT/Schneider/Siemens

Specifications of Mesh Belt Sinter Furnace

SpecModel	MBSF-150/65-4	MBSF-220/80-5	MBSF-300/100-6	MBSF-460/100-7	MBSF-610/125-7
Belt (mm)	150	220	300	460	610
Muffle (mm)	65	80	100	100	125
Heating zone	4	5	6	7	7
Heating zone length (mm)	1500+3600	2600+3600	2600+6000	4600+6000	4600+6000
Max.temperature (°C)	1150	1150	1150	1150	1150
Temperature Uniformity (°C)	±5	±5	±5	±5	±5
Heating Power (kW)	60	90	120	250	400
Process gas of mesh belt sintering furnace	N₂/3H₂+N₂/H₂/CH₄	N₂/3H₂+N₂/H₂/CH₄	N₂/3H₂+N₂/H₂/CH₄	N₂/3H₂+N₂/H₂/CH₄	N₂/3H₂+N₂/H₂/CH₄
Gas consumption (m³/h)	6	10	15	20	30
Total size L×W×H (mm)	13500 × 1300 × 1600	15500 × 1400 × 1700	20000 × 1500 × 1800	23500 × 1700 × 1900	23500 × 1900 × 2000
The above specifications are defined according to ferrous part sinter. The above parameters can be adjusted to the process requirements, they are not as acceptance standard, the detail spec. will be stated in the technical proposal and agreements.
