We are a leading manufacturer of foam fire engine,also names fire engine,fire truck,fire fight truck,we can provide customers all kinds of foam fire engine, with competitive price and high quality,Following is the detail feature of fire engine ,any question, please feel free to contact me.
we can provide various configurations trucks with best prices and best quality.
1.Type:water tanker fire fighting truck, foam tanker fire fighting truck, emergency rescue fire fighting truck, command and communication fire fighting truck, etc;
2.Drive model:4*2, 4*4, 6*4;
3.Capacity:3-15CBM;
4.Tank material:carbon steel, stainless steel,etc;
5.Cab:single row or double rows , left hand drive/right hand drive, with A/C;
6. Fire pumps: middle pressure pump,low pressure pump,high pressure pump, ordinary pressure pump,etc;
7.Other descriptions:equipment box with 5-9 curtain doors,truck body with stoving varnish, 1100-1600mm alarm lamp,the truck can be equiped with all kinds of fire fighting equipment.
Item |
unit |
parameter |
|||
Vehicle model |
|
CLW5321GXF Fire truck |
|||
Chassis model |
|
EQ1120GLJ |
|||
Overall dimensions |
mm |
8300X2500X3300 |
|||
|
Fact water cubage |
L |
6000 |
||
Fact Foam cubage |
L |
2000 |
|||
Mass in working order |
|
Appro×14650 |
|||
Wheel base |
mm |
5100 |
|||
F/R track base |
1250/2650 |
||||
Approach/departure angle |
° |
32/12 |
|||
Exhaust/kw |
ml/kw |
4500/132 |
|||
Max speed |
km/h |
85 |
|||
Tire specification |
9.00-20 |
Engine type |
ISDe180 20 |
||
Traction system |
4*2 |
transmission |
6-speed with over drive |
||
Number of axles |
2 |
Electric system |
24v |
||
Operation control system |
Electrically hydraulic control |
Allowable passengers in cab |
8 |
||
Equipment |
Fire extinguishing pump |
Model: CB20.10/15.30H low pressure flow:30L/s/1.0MPa middle pressure flow:15L/S/2.0Mpa, Max deep :7m |
|||
Fire monitor |
PP32 ,flow :48L/s/1.0Mpa water throw range:≥50m foam throw range:≥45m |
||||
accessory |
With smoke ejector,5Nos.dry powder fire extinguishers 2Kg with pressure meter |
||||
|
Fire hoses(1.5inch)---8Nos500feet Suction hoses(4inch)3Nos10 feet 1.5inch fire nozzles One reel hose on either side60M Aluminum Ladder 9M | |||||
Engine |
Commins |
||||
Production cycle |
10-15days |
||||
Warranty |
12 month,from the date of supply |
||||
