Home > Transportation > Specialized Vehicle > Refrigerated Truck > 2-3 t Ice Car Delivery, Refrigerated Cold Room Van Truck,refrigerated Small Trucks

2-3 t Ice Car Delivery, Refrigerated Cold Room Van Truck,refrigerated Small Trucks

2-3 t Ice Car Delivery, Refrigerated Cold Room Van Truck,refrigerated Small Trucks photo-1
US$ 5,000 - 11,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
CLW
Model:
EQ1060TJ20D3
Place of Origin:
China
Payment & Shipping
Payment Methods:
Port of Shipment:
any port of China
Delivery Detail:
Delivery time depends on order quantity.
Brand Name CLW
Model EQ1060TJ20D3
Place of Origin China
Transmission Type Manual
Condition New
Emission Standard Euro 3
Fuel Type Diesel
Dimensions (L x W x H) (mm) 5900*2000*2700
Box Dimensions (L x W x H) (mm) 4200*1700*1700
Temperature Range -20 ~ -15
Gross Vehicle Weight 7450

Refrigerated Small Trucks,Refrigerated Cold Room Van Truck,Ice car delivery

Chassis Description

Chassis model: EQ1060TJ20D3

a) Overall dimensions: 5995x1930x2950mm

b) G.V.W: 4050 Kg

c) Mass in working order: 2455Kg

d) Fact load capacity: 3500Kg

e) Wheelbase: 3300mm

f) F/R track base: 1380/1458 mm

g) Approach/departure angle: 23/15°

h) Exhaust/hp: 2398ml/ 66Kw

i) Max. Speed: 95km/h

j) Tire specification: (6 pieces) 7.00-16

k) Engine type: CY4102-C3F,Dong-feng Chaoyang Brand

l) Number of axles: 2

m) Leaf spring:5/8+4

n) Allowable passengers in cab: 2

o) Horse Power: 90ps



Truck refrigerator

Temperature scope: -20~-15 degree

Refrigerator Type: DT-150S

Evaporator

Main parameters for DT-150S

Unit model

DT-150S

Applicable temperature (°C)

-5~-18

Applicable volume(m3)

4-6

Cooling capacity

Environmental

temperature

0°C

2850

-18°C

1450

Voltage (V)

12/24

Current (A)

27/17

compressor

Displacement (cc/r)

105

condenser

Air flow (m3/h)

550

Fan type

Axial fan

number

1

evaporator

Air flow (m3/h)

1000

Fan type

Axial fan

number

2

refrigerant

R134a/R404a

Refrigerant charge amount(Kg)

0.8

Defrost type

Hot gas defrost

Dimensions(mm)

evaporator

575x425x170

Condensing utensil

910x385x170

Weight(KG)

evaporator

12

Condensing utensil

23

Remark

Optional to install for 380v store electric power



More Picture Show :



2-3 t ice car delivery, refrigerated cold room van truck,refrigerated small trucks

2-3 t ice car delivery, refrigerated cold room van truck,refrigerated small trucks

2-3 t ice car delivery, refrigerated cold room van truck,refrigerated small trucks
