Help CenterBuffer Drop Impact Tester
Negotiable
MOQ: 1 Square Meter (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Hebei, China
Brand Name:
JC
Model Number:
LCJ-1
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Hebei, China
Brand Name
JC
Model Number
LCJ-1
Specifications
The buffer drop impact tester accomplishes the impact test of railway buffer promptly, accurately and reliablyThe detailed technical specification of buffer drop impact tester is following:
Performance feature:
1. The advanced displacement and pressure transducer could assure the high precision and reliability.
2. Human-computer interaction displays the value of pressure and displacement real-time.
3. The testing could be controlled manually or automatically.
4. The data could be stored, printed and shared.
Technical parameters:
1.Outline dimensions: 3500mm×800mm×3600mm;
2.Height precision: ±1mm;
3.Stroke precision: ±0.5mm;
4.Weight: 70T;
5. The pressure of hydraulic system:
1) Lifting mechanism: 12Mpa;
2) Arrester hooker: 4Mpa;
6. Testing efficiency: 5min per piece;
7. Testing height range: 0~400mm;
8. General power: 10Kw.
Application:
Railway factory or depot
