Wheel Set Automatic Tester

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Hebei, China

Brand Name:

Model Number:

LDJ-2

CRRC Shijiazhuang Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Xingang

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Hebei, China

Brand Name JC

Model Number LDJ-2

Power Other, electronic and pneumatic

Usage Other, dimension and deformation tester

Specifications

The wheelset automatic tester could detect the dimensions and process the data automatically, precisely.

the main technical specification is following:

Measurement range and precision grade:

Measuring point	Measuring range(mm)	Measuring precision(mm)
wheel diameter	740~850	0.2
wheel rim thickness	10~80	0.2
wheel rim width	120~150	0.15
Distance between backs of wheel flanges	1345~1365	0.15
Flange wheel thickness	10~40	0.2
Tread wear	-5~10	0.2
Axle diameter on center	160~190	0.2
Eccentricity	0~8	0.2
Positioning errors of wheel	10	0.2
Wheel set diameter	180~220	0.1
Journal collar diameter Dust guard seat diameter	128~182	0.01
Journal collar length	200~230	0.2
Technical Parameter: Electric Power:AC380V±20V,50Hz,5Kw; Measurement Time: 3min per set; Outline dimensions:3300mm×4150mm×1550mm; Pressure:0.5~0.8MPa Temperature:10~30 Relative humidity:85%. Performance and Features: The untouched optical measuring method has been developed with the independent IPR. The system is integrated by using the CCED, optical, ultrasonic, computer and micro-electronics technology. Without the measuring table and complex mechanism, the wheelset automatic tester could achieve measurement, data processing and information management automatically. Function: 1. It could measure the dimensions on the wheelset automatically. 2. The detection results could be saved, printed and networked with HMIS system automatically. 3. The tester realizes automatic calibration 4. It could diagnose the error real-time.
