Home > Products > Feeder and conveyor machine > Stainless Steel Flexible Spiral Conveyer for sugar
Stainless Steel Flexible Spiral Conveyer for sugar
- 100 Set / Sets per Month
- Tianjin / Shanghai / Qingdao
- T/T Credit Card
Product Details
| Condition: | New | Application: | Conveyor System, fly ash, cement powder, gypsum powder | Power Type: | Electric |
| Capacity(t/h): | 15-60 ton/h | Place of Origin: | Henan, China | Brand Name: | GAOFU |
| Model Number: | GZ315 screw conveyor | Power(W): | 5.5-30kw | Dimension(L*W*H): | 100mm/250mm/800mm, as requested |
| Weight: | 260KG | Certification: | ISO9001:2008, CE, BV | Warranty: | 12 Months, One year |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
make sure meet the export standard
Product Description
Gaofu stainless steel sugar spiral conveyer
Sugar spiral conveyer introduction:
Xinxiang hengyu stainless steel sugar spiral conveyer is the new equipment designed by our company after integrating our rich experience of producing the other series screw conveyor, based on absorbing the foreign similar products. Since this series screw conveyor cans not only horizontal but also much aslope transport materials, it is widely used to transporting the bulk material, such as the cement, fly ash in concrete mixing plant and cement transfer-warehouse etc.
Technical parameters:
model | Spiral diameter(mm) | Pitch(mm) | Spiral speed(r/min) | MAX transport capacity(m3/h) | Motor power(kw) | Admission biggest gradient(°) |
GZ100 | 100 | 100 | 140 | 2.2 | 2.2---18.5 | ≤ 60. |
GZ 125 | 125 | 125 | 125 | 4.0 | ||
GZ 160 | 160 | 160 | 112 | 8 | ||
GZ 200 | 200 | 200 | 100 | 11 | ||
| GZ-250 | 250 | 250 | 90 | 22 | ||
GZ 315 | 315 | 315 | 80 | 34 | ||
GZ 400 | 400 | 355 | 71 | 64 | ||
GZ 500 | 500 | 400 | 63 | 95 | ||
GZ 630 | 630 | 450 | 50 | 150 |
Function of sugar spiral conveyer
Xinxiang hengyu stainless steel sugar spiral conveyer in modern industry is an efficient way to move semi-solid materials including food, wood chips, aggregates, cereal grains, animal feed, boiler ash, meat and bone meal, municipal solid waste, and many others. It is often used horizontally or at a slight incline.
Customer site
Before selecting the right model of sugar spiral conveyer, please inform us the following information:
1. Length.........L=??m
2. Output/Capacity/Throughout.......?M3/Hr ??
3. Made of Stainless steel or carbon steel??
4. Voltage of your location: it is 380V,50HZ,3PH in China ??
5. Working continuous or not ??
6. Incline degree if necessary ??
Believe in us, best quality of sugar spiral conveyer will be offered to you; here please send us your e-mails now.
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Contact Us
- Xinxiang Gaofu Machinery Co., Ltd.
- Contact namemei He
- Phone86-373-5702900,5702903, 570290
- Addresslanggongmiao Xinxiang,Henan
-
