Home > Products > Feeder and conveyor machine > Gaofu Vibration Feeder Machine
Gaofu Vibration Feeder Machine
- 20 Set / Sets per Month
- According to your request
- T/T L/C D/P D/A
Product Details
Condition: | New | Type: | Other, Linear, Full-closed type feeder Machine | Application: | Ore |
Place of Origin: | Henan, China | Brand Name: | GAOFU | Model Number: | ZG-400-Q235A |
Voltage: | 220V/380/415V or others | Power(W): | 2.0*2KW | Dimension(L*W*H): | 1456MM*1268MM*720MM |
Weight: | 686KG | Certification: | CE/SO9001:2008/BV/SGS | Warranty: | 12 month |
After-sales Service Provided: | Engineers available to service machinery overseas |
Packaging Details
standard containers,bare main machine, motors and small parts are packed in wooden cases
Product Description
vibration feeder machine
1.Summary description:
ZG series motor vibrator feeder is a kind of general feeding device, which tends to standardization. It is widely applicable for relevant industries to convey all kinds of block, particle and dust materials in short distance. The feeder can well implement the on-line and automatic operation with continuous conveying system like belt, automatic scaling and quantitative packing system etc. It is an ideal feeding and conveying device for the industries of metallurgy, mining, coal, construction material, chemical, power, and grain process.
ZG series motor vibrator feeder compared with electromagnetic vibrating feeder and reciprocating feeder have the advantages of compact and easy structure, durable and sturdy, continuous and homogeneous feeding, and low wear of trough, long service life, and convenient maintaining. The feeder has two structure forms, open and closed, according to the requirements of field working environment; motor could be installed on upper, lower or side face in order to form three different vibrating source installation positions.
According to the requirements of user and field operation, the feeder has several choices of joint devices such as seated or suspended installments, and allocating control valve, working table or not.
2. Motor vibrator feeder Specification:
Model | Feed size(mm) | Capacity (t/h) | Motor | Power (KW) | Double amplitude | Weight(KG) | |
Close | Open | ||||||
ZG-25 | 60 | 25 | YZO-2.5-4 | 0.25*2 | 2-3 | 240 | 174 |
ZG-30 | 80 | 30 | YZO-5-4 | 0.4*2 | 2-3 | 256 | 184 |
ZG-50 | 90 | 50 | YZO-5-4 | 0.4*2 | 2-3 | 295 | 235 |
ZG-100 | 105 | 100 | YZO-8-4 | 0.75*2 | 2-5 | 384 | 321 |
ZG-200 | 115 | 200 | YZO-17-4 | 0.75*2 | 2-5 | 432 | 372 |
ZG-400 | 140 | 400 | YZO-20-4 | 2.0*2 | 2-5 | 686 | 606 |
ZG-750 | 190 | 750 | YZO-30-4 | 2.5*2 | 4-6 | 1258 | 1030 |
ZG-1000 | 215 | 1000 | YZO-50-4 | 3.7*2 | 4-6 | 1446 | 1156 |
Note: This specification is just for reference, any changes are subject to the products.
3. Machine disply:
4. Customer visit
GAOFU company have a perfect after-sales service system and professional technology team to provide customers with prompt and thorough service. Our price are most competitive and reasonable, all order will be supplied within the stipulated period. Awaiting your first inquiry order
If you are interest in our machine, please don't hesitate to contact with me.
Company Profile
Xinxiang Gaofu Sieving Machinery Co., Ltd. specializes in manufacturing vibration screens and vibrating sieves. To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
Thanks to production equipment, strong technical capabilities, improved detection means and strict managing system, we have enjoyed good reputation.
our company has attained ISO9001:2000 certification and CE Certification. Our products sell well throughout China and are exported to North America, West Europe, Southeast Asia and other countries and regions.
Do you want to improve your product quality? Do you want your products to become more competitive? Choosing Xinxiang Gaofu Sieving Machine Co., Ltd.! We will be your friend in the way to success! And you will create a shiny future in 2014!
Please visit our website: www.gaoful.com.
Our tenet: "Honest Service, the Highest Quality".To solve sieving problems in all fields, we can manufacture all kinds of vibrating screens to meet the different needs of customers.
