HUALI brand 75.2 KW With Water Tank and Pump Industry Water Chiller
Production Description:
Golden industrial air cooled chiller:
1. Convenient for installation and operation;
2. Integrated electronic control, microcomputer display.
3. One-stop automatic intelligent temperature control: in different environment, user does not need to change setting due to it will automatically switch to appropriate operating temperature.
Questions about our water chiller and product:
1. How to choose suitable industrial air cooled chiller?
* Cooling capacity.
* Water flow.
* Inlet temperature and outlet temperature.
2. Why do you choose our company?
* CE certified.
* High quality.
* Competitive price.
* Beautiful appearance.
3. What is the MOQ, Payment, Packaged, Warranty?
* MOQ: 1 Set.
* Payment: 30% as deposit, 70% before delivery.
* Packaged: Wooden packaged.
* Warranty: For one year.
Product Detail:
Model HLLA ~ |
25DI |
|
Rated Cooling Capacity |
×1000 kcal/h |
64.7 |
KW |
75.2 |
|
Input Power (KW) |
22.5 |
|
Comp. Input Power×Qty. (KW) |
9.3×2 |
|
Chillded Water Pump Model |
HT50-17 |
|
Chilled Water Pump Power (KW) |
1.5 |
|
Comp. Current (A) |
37.2 |
|
Power Supply |
3φ-380V-50HZ |
|
Safety Protection |
Phase reversion protection, Phase lack protection, Overload current protection, |
|
Number of Refrigeration Circuit |
2 |
|
Capacity Control (%) |
0, 50, 100 |
|
Refrigerant |
R22 |
|
Condenser |
Ripple Aluminum Fins around Cooper Pipe |
|
Power lnput of Fan (KW) |
2.4 |
|
Evaporator |
Shell and Tube Type |
|
Water Side Max Pressure (MPa) |
1 |
|
Dia.of Pipe to Evaporator (inch) |
2" |
|
Chilled Water Flow (L/m) |
194.8 |
|
Evaporator Water Pressure drop (kPa) |
28 |
|
Running Noise dB(A) |
75 |
|
Tank Volume (L) |
270 |
|
Total weight (Kg) |
880 |
|
Dimension L×W×H |
2200×1180×2200 |
|
Product Show:
Product Certificate:
| Company profile |
|
Shenzhen Jinhuali Technology Co.,Ltd. is a modern large enterprise, which integrates technology, industry and trade. It is a professional enterprise that provides central A/C, refrigeration plant, eletromechanical device, electric equipment and electronics, as engineering design and installation service. HUALI takes an area of over 100,000m2 with an asset of more than 100 millions and empolyee of more than 500 persons, and its has 5 branch companies in the rest of China.
|
