Good quality HLLA~12.5SI 32.4 KW Cooling capacity Industrial Air Cooled Chiller
Production Description:
Golden chiller consists of compressor, control panel, condenser, evaporator
and water pump, water tank.
You can choose the type and brand of these components yourself .
1. Compressor
Our standard industrial water cooled chiller use the famous Copeland scroll compressors. If you have requirement of compressor, pls tell us the brands you need.
2. Control Panel
Normally, scroll chiller is equipped key control panel with LED display (Punp Brand).
3. Condenser
Finned type condenser: Ripple aluminum fins around copper pipe, can be titanium coil tube type or stainless plate type.
4.Evaporator
The evaporator of our air cooled chiller is shell and tube type.
5. Water Pump
The air cooled industrial chiller has inside water pump and water tank, easy installation, it doesn’t need to compact cooling tower and other water tank.
6. Water Tank
Different models with different sizes of water tank: 80L~270L.
Product Function:
Injection Industry
Golden chiller can accurately control the temperature of mold which can improve the quality and production rate.
Electronic Component Industry
Golden chiller can stabilize the molecular structure of electronic component inside. This can improve the FTQ and product time.
Machinery Industry
Golden chiller can cool down the oil for the machine and stabilize the oil temperature and pressure. It’ll extend the useful life of oil. And it can also improve mechanical lubrication efficiency.
Electroplating Industry
The temperature of electroplate can be controlled by our chiller. It can improve the density and smooth of electroplate and production efficiency.
Food & Drink Processing Industry
The temperature of processed food and drink will be too high to be packaged. Golden chiller can cool it down through food grade stainless steel heat exchanger.
Product Detail:
Model HLLA ~ |
12.5SI |
|
Rated Cooling Capacity |
×1000 kcal/h |
32.3 |
KW |
37.6 |
|
Input Power (KW) |
12.0 |
|
Comp. Input Power×Qty. (KW) |
9.3 |
|
Chillded Water Pump Model |
HT50-17 |
|
Chilled Water Pump Power (KW) |
1.5 |
|
Comp. Current (A) |
20 |
|
Power Supply |
3φ-380V-50HZ |
|
Safety Protection |
Phase reversion protection, Phase lack protection, Overload current protection, |
|
Number of Refrigeration Circuit |
1 |
|
Capacity Control (%) |
0, 100 |
|
Refrigerant |
R22 |
|
Condenser |
Ripple Aluminum Fins around Cooper Pipe |
|
Power lnput of Fan (KW) |
1.2 |
|
Evaporator |
Shell and Tube Type |
|
Water Side Max Pressure (MPa) |
1 |
|
Dia.of Pipe to Evaporator (inch) |
2" |
|
Chilled Water Flow (L/m) |
107.8 |
|
Evaporator Water Pressure drop (kPa) |
28 |
|
Running Noise dB(A) |
75 |
|
Tank Volume (L) |
180 |
|
Total weight (Kg) |
510 |
|
Dimension L×W×H |
1500×1100×2200 |
|
Product Show:
Product Certificate:
| Company profile |
|
Shenzhen Jinhuali Technology Co.,Ltd. is a modern large enterprise, which integrates technology, industry and trade. It is a professional enterprise that provides central A/C, refrigeration plant, eletromechanical device, electric equipment and electronics, as engineering design and installation service. HUALI takes an area of over 100,000m2 with an asset of more than 100 millions and empolyee of more than 500 persons, and its has 5 branch companies in the rest of China.
|
