Product Description
modular heat recovery air cooled chiller
1) Recover thermal energy to produce free hot water
2) Ideal solution for providing cooling, heating, hot water for family, villa, apartment, business restaurant, hotel and multi-floor living building in city and village etc.
3) Provide full technical support for project, solution.
4)12 months warranty.
Model |
Unit |
YH3P |
YH6P |
Cooling capacity |
KW |
7 |
14 |
Heating capacity |
KW |
9.2 |
18.5 |
Power input |
KW |
2.2 |
4.4 |
Rated current |
A |
7.8 |
12 |
COP |
3.2 |
3.2 |
|
Max water temperature |
℃ |
60 |
60 |
cooling Water flow |
m3/h |
1.2 |
2.4 |
heating Water flow |
m3/h |
0.8 |
1.6 |
Net weight |
kg |
45 |
100 |
Gross weight |
kg |
52 |
110 |
Noise |
dB |
65 |
65 |
Water connections |
DN50 |
DN50 |
|
Power supply |
380V/3/50HZ |
380V/3/50HZ |
|
Net dimensions |
mm |
840X310X600 |
700X700X900 |
Packing dimensions |
mm |
880X350X640 |
740X740X940 |
Heating capacity Test Condition |
Ambient temp.24ºC/15ºC, cooling Water inlet/outlet temp.12/7℃, Heating Water inlet/outlet temp.50/60℃ |
||
Packaging & Shipping
Export package-standard carton box is free from us.
We will responsible for the shipping charge from our factory to the shipping port.
Company Information
Established in 2014, Yunhong Energy Technology Energy Co., Ltd. is a manufacturer specialized in the research, development and production of heat pump water chiller/heater units. We are located in Guangzhou, with convenient transportation access. All of our products comply with international quality standards and are greatly appreciated in a variety of different markets throughout the world.
